Suda SL1290 80W Laser Marking Machine

Name: Suda SL1290 80W Laser Marking Machine
Brand: Suda
SKU: 144391090
Availability: InStock

US$ 5,800 - 5,900 MOQ: 1 Set

Key Specifications

Condition:

New

Laser Type:

CO2

Applicable Material:

Acrylic, Glass, MDF, plastic, Plywood, Rubber, Stone, Wood

Tongxing Technology Development Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Laser Type CO2

Applicable Material Acrylic, Glass, MDF, plastic, Plywood, Rubber, Stone, Wood

CNC or Not Yes

Cooling Mode Water Cooling

Graphic Format Supported DXF, DWG, DXP

Place of Origin Anhui, China

Brand Name Suda

Model Number SL1290

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

SL1290 LASER MARKING MACHINE
DSP controlling system,
80W LASER TUBE
UNIVERSAL LASER MACHINE
CE

Suda small laser machine SL1290

1 working size:1200*900mm

2 upgrading structure, high precision and higher speed

3 with advanced DSP controlling system, strong function, can effectively engrave on plane/ gradient(optional0, cutting and drilling holes, etc.

4 transmitting files directly from CorelDraw, Auto CAD etc.

5 equipped with lifting platform which can perform processing at any height

6 the delicate machine body, adopting DSP controlling system to ensure work without computer and support USB flash disk direct output.

Laser engraving/cutting machine SL1290

Power	80w
Laser type:	SL1290
Power supply:	AC220V±10%,50HZ
Working area:	1200*900mm
Max cutting speed:	200mm/sec
Max engraving speed:	2000mm/sec
Worktable:	Lifting platform
Locating precision:	0.1mm
Min shaping character:	Engrving 0.8mm, cutting 2mm
Operating temperature:	0°c-45°c
Work degree of humidity	5-95%(have no Ning water)
Resolution ratio:	0.025mm
Control configuration:	Advanced DSP controlling system
Data transfer interface:	USB flash disk / directly from computer
System environment:	Above Window 2000, window XP
Cooling way:	Water cooling
Graphic format supported:	BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,DXF, etc.
Compatible software	Transmit files directly form Coreldraw, AutoCAD, etc.
Cutting thickness	6mm
Color separation	200
Sloping engraving	90°--180°
Cuts off the water supply the protection	yes
Machine dimention	1000840710mm
Red point as standard	not
Air pump as standard	Yes
Net weight	480kg
packing	Standard non-woody
