SUDA Rotary Device Laser Machine Laser Cutter -SL1290

Name: SUDA Rotary Device Laser Machine Laser Cutter -SL1290
Brand: SUDA
SKU: 144390812
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Laser Type:

CO2

Place of Origin:

Anhui, China

Brand Name:

SUDA

Tongxing Technology Development Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Laser Type CO2

Place of Origin Anhui, China

Brand Name SUDA

Model Number SL6040,9060,1216,1290

Specifications

SUDA ROTART DEVICE LASER MACHINE
Applicable to material :Acrylic ,PVC board woody products,Bamboo ware
CE

Laser engraving/cutting machine SL1290

Laser power :	80W
Laser type:	SL1290
Power supply:	AC220V±10%,50HZ
Working area:	1200*900mm
Max cutting speed:	200mm/sec
Max engraving speed:	2000mm/sec
Worktable:	Lifting platform (optional )
motor	Standard stepper, SERVO import from Japan ( optional)
Locating precision:	0.1mm
Min shaping character:	Engrving 0.8mm, cutting 2mm
Operating temperature:	0°c-45°c
Work degree of humidity	5-95%(have no Ning water)
Resolution ratio:	0.025mm
Control configuration:	Advanced DSP controlling system
Data transfer interface:	USB flash disk / directly from computer
System environment:	Above Window 2000, window XP
Cooling way:	Water cooling
Graphic format supported:	BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,DXF, etc.
Compatible software	Transmit files directly form Coreldraw, AutoCAD, etc.
Cutting thickness	20mm
Color separation	200
Sloping engraving	90°--180°
Cuts off the water supply the protection	yes
Machine dimention	194014401380mm
Red point as standard	not
Air pump as standard	Yes
Gross weight	480kg
packing	Standard non-woody
