Chinese cantilever cnc machining center furniture working machine
- 100 Set / Sets per Month
- Shanghai
- SUDA heavy duty static Column CNC machine center
- China SUDA Wood CNC router Wood Engraving Machine HP3313 for door and furniture making with CE
- China SUDA high qualitycnc router Wood Engraving Machine for door and furniture making with CE 3500*1500*250MM
- sell China SUDA 3D CNC Router Wood Engraving Machine with CE,imported linear rail
- 1300x2500mm Furniture Making Woodworking Cnc Machine For Sale
- SUDA HOT SALE 1300x2500mm Furniture Making Woodworking Cnc Machine cheap price
Product Details
Condition: | New | CNC or Not: | CNC | Place of Origin: | Anhui, China |
Brand Name: | SUDA | Model Number: | MP2513 | Voltage: | AC380V/3PH/50HZ |
Dimension(L*W*H): | 3200*2100*2000mm | Weight: | 3500kg | Certification: | CE |
Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Italy 10KW ATC spindle motormatrix vacuum table
side feeding material
one-armed gantry
Chinese cantilever cnc machining center furniture working machine
Performance Features:
1.Side Feeding Material of new design,more convenient.one-armed gantry of high strength,more efficiency.
2.Integral welding frame of industrial,tempering vector efficiency of processing,without deformation,improve
stability and precision of machine.
3.Transmission part adopts high precision helical rack THK linear rail from Japan Yaskawa servo system and
Taiwan professional deceleration device,ensure machine running smoothly in high speed,high precision,low noise.
4.Equipped with professional vacuum system,adopt adsorption base of integral steel structure,specialized material
matrix surface with high strength and toughness,adopt professional “Becker”vacuum pump from German,strong
adsorption capacity,high efficiency.
5.Industrial controlling system,professional and perfect function,stable performance,strong software compatibility.
6.Thousands of classification precision hidden non-interference automatic tool feeding,one operation can finish whole database work,automatic lifting dust head,
automatic oil lubrication system,more convenient,simple maintenance.
Technical data:
Item | MP2513 | MP3015 |
Working size | 2500×1300×210mm | 3000×1500×210mm |
Table size | 2440×1220mm | 2940×1430mm |
Max.travel speed | Xaxis-60m/min. Yaxis-40m/min. Zaxis-20m/min | |
transmitting | X.Y-high accuracy helical gear. Z-rolling ball screw | |
Servo type | Japan YASKAWA | |
spindle | Italy 10kw ATC spindle motor | |
Spindle rev. | 18000-24000rpm | |
Vacuum table | Matrix vacuum tab | |
Pump type | Moporo(Germany Becker is optional) | |
Tool type | Geneva Type | |
Tool magazine | 8pcs(10pcs,12pcs is optional) | |
Controlling system | SYNTEC(OSAL is optional) | |
voltage | AC380V/3PH/50HZ | |
Machine size | 3200×2100×2000mm | 3700×2300×2000mm |
weight | 3500KG | 4200KG |
Application
Applicable to process kinds of plate material, such as MDF, shaving board,PVC, fire-proof board, engineering plastics etc , widely used in solid wood doors, cabniets, bathroom cabinet
Company Profile
Tongxing Technology Development Co., Ltd. is located in one of the Chinese Science & Technology Cities, Hefei City. Since foundation in 1992, we have been researching and developing digital products in advertising and mould processing, and have been a very manufacturer in advertising equipment.
Our main products range is as follows: Suda vanguard series CNC engraver, Suda powerful CNC engraver, Suda luck series CNC engraver, Suda laser engraver, Suda cutting plotter, Suda afflatus cylinder CNC engraver, Suda plasma cutting machine.
We have superior staff adhering to the motto of Sincere Operation. The style of designing delicate products has been accepted by customers both at home and abroad. Our products have been exported to many countries and regions such as South-east Area, the Middle East, Europe and America.
Tongxing is willing to cooperating with you based on mutual benefits based on brilliant future.
