Specifications
fixed beam gantrysuper thick steel material
Japanese YASKAWA servo system
SUDA heavy duty static Column CNC machine center
Performance features:
1.Steel machine frame,professional engineering mechanical structure&dynamic design,high tempering
treatment,enhance rigidity of machine,avoid deformation of machine,improve stability and precision of machine.
2.Transmission part adopts high precision helical rack,THK linear rail from Japan,supplement with Japan Yaskawa
servo system and Taiwan professional deceleration device,ensure machine running smoothly in high speed,
high precision,low noise.
3.Configured with imported gang drill,can be arbitrary permutation and combination of vertical drilling,sidetracking,
single drill,and other multifunction drill mode.
4.Imported high power spindle from Italy,low sway in axial,strong cutting force,long lifetime,low noise.with imported
Geneva Type library of 8pcs tool,high efficiency.
5.Industrial control system,professional electronic parts,prefect function,stable performance,strong compatibility of
software.
6.Equipped with professional vacuum system,adopt adsorption base of integral steel structure,specialized material
matrix surface with high strength and toughness,adopt professional “Becker”vacuum pump from German,strong
adsorption capacity,high efficiency.
7.Thousands of classification precision hidden non-interference automatic tool feeding,one operation can finish whole database work,automatic lifting dust head,
automatic oil lubrication system,more convenient,simple maintenance.
Technical data:
Item |
HG1325 |
HG1630 |
HG2040 |
Working size |
1650×2750×280mm |
1950×3300×280mm |
2350×4300×280mm |
Table size |
1220×2440mm |
1530×2940mm |
1830×3800mm |
Max.travel speed |
Xaxis-30m/min.Yaxis-30m/min.Zaxis-20m/min |
||
transmitting |
X.Y-high accuracy helical gear.Z-rolling ball screw |
||
Servo type |
Japan YASKAWA |
||
spindle |
Italy 10KW ATC spindle motor |
||
Spindle rev. |
18000-24000rpm |
||
Vacuum table |
Matrix vacuum table |
||
Pump type |
Moporo(Germany Becker is optional) |
||
Tool type |
Geneva Type |
||
Tool magazine |
8pcs(10pcs,12pcs is optional) |
||
Controlling system |
SYNTEC(OSAI is optional) |
||
Power supply |
AC38V/3PH/50HZ |
||
Machine size |
3500×2600×2000mm |
4000×2900×2000mm |
5000×3300×2000mm |
weight |
2200KG |
2950KG |
3600KG |
