Gift Paper Bag Laser Marking Machine With IPG Fiber Laser Source

Name: Gift Paper Bag Laser Marking Machine With IPG Fiber Laser Source
Brand: Perfect Laser
SKU: 144364892
Availability: InStock

Perfect Laser (Wuhan) Co., Ltd.

US$ 2,000 - 5,000 MOQ: 1 Set

Key Specifications

Condition:

New

Laser Type:

Fiber Laser

Engraving Area:

110*110mm / 175*175mm / 300*300mm

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI OR SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Laser Type Fiber Laser

Engraving Area 110*110mm / 175*175mm / 300*300mm

Engraving Speed max 7000mm/s

CNC or Not Yes

Cooling Mode Air Cooling

Applicable Material Acrylic, Crytal, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood

Graphic Format Supported BMP, DWG, DXF, DXP, Other, BMP, DWG, DXF, DXP, Graphics, Text, Bar Codes, QR Code

Place of Origin Hubei, China

Brand Name Perfect Laser

Model Number PEDB-100

Dimension(L*W*H) 60*30*50mm

Certification CE, ISO

After-sales Service Provided Engineers available to service machinery overseas

Gift Paper Bag Laser Marking Machine with IPG fiber laser source

Application Field and Material :

Electronic Component:	Resistance, capacitance, chips, printed circuit boards, computer keyboard.
Apparatus and Meter:	Panel Signs, Precision equipment, etc
Instrument:	Panel Sings, Nameplates, Medical Instruments
Hardware Tools:	Knives, tools, measuring tools, cutting tools, etc.,
Automobile Parts:	Pistons, piston rings, gears, shafts, bearings, clutch, lights, etc.,
Mechanical Parts:	Bearing, Gears, Standard Parts, Motors,etc
Daily Necessities:	Handcrafts, Zipper, Key Holder, Sanitary Wares, etc
Jewelry:	Jewelry, Rings, Gold & Silver Parts
Food Drinking Parking:	Plastic Packing, etc

Technical Data

Technical Data	PEDB-100
Output power	10W	20W
Central wavelength	1064±4nm	1064±4nm
Polarization	Random	Random
Single pulse power	0.5~0.6mJ	0.8~1.0mJ
Facular diameter	6~8mm	7~9mm
Power stability	<5%	<5%
Frequency adjusting range adjustable range	20~80kHz	20~80kHz
Pulse breadth	80~140ns	80~140ns
Pulse adjusting range	5~100%	5~100%
operating voltage	100~240VAC	100~240VAC
Fiber Length	1.5m	1.5m
Cooling mode	forced air	forced air
Operation temperature	0~35℃	0~35℃
Operation humidity	10~95	10~95
Storage temperature	-10~60℃	-10~60℃
Marking Format	Graphics, Text, Bar Codes, QR Code, Serial Number,Serial number,etc.
