1530 500w /1000w Fiber Laser cutting machine for metal 1mm-14mm
contact person:Jessica whats app:0086 13886024827 skype:perfectlaser015
1. Description for metal business card laser cutting machine:
Fiber metal business card laser cutting machineadopts the most sophisticated Germany IPG laser, combining Gantry CNC machine designed by our company. It has good rigidity and stability with precision ball screws, linear guide drive run. It is mainly for cutting sheet metal in high speed and high precision. Fiber laser has a series of advantages, such as high beam quality, high brightness, high conversion rates, maintenance-free, stable and reliable operation of low cost and small size, etc. Air-assisted cutting is the most advanced level of laser cutting, which is particularly suitable for titanium, alloy steel, copper, titanium and other metal materials' precision cutting. It is widely used in metal products, hardware, precision machinery, auto parts, glasses, jewelry, nameplate, electronics, toys, advertising and other industries
2. Features for metal business card laser cutting machine:
1)Excellent beam quality: Smaller focus diameter and high work efficiency, high quality.
2)Fast cutting speed: Cutting speed is more than 20m/min
3)Stable running: Adopting the top world import fiber lasers, stable performance, key parts can reach 100,000 hours;
4) High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, Fiber metal business card laser cutting machinehas 3 times photoelectric conversion efficiency
5) Low cost & Low maintenance: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine. Fiber line transmission no need reflect lens, save maintenance cost;
6) Easy operations: fiber line transmission, no adjustment of optical path;
7) Super flexible optical effects: Compact design, easy to flexible manufacturing requirements.
3. Application for metal business card laser cutting machine:
Fiber metal business card laser cutting machineapplied in sheet metal processing, aviation, spaceflight, electronics, electrical appliances, subway parts, automobile, machinery, precision components, ships, metallurgical equipment, elevator, household appliances, gifts and crafts, tool processing, adornment, advertising, metal foreign processing various manufacturing processing industries. Mainly used for carbon steel cutting, titanium cutting, titanium cutting, titanium cutting, titanium alloy cutting, galvanized steel sheet cutting, pickling board cutting, aluminum zinc plate cutting, copper cutting and many kinds of metal materials cutting and so on.
4. Technical Date for metal business card laser cutting machine :
Model |
PE-F200 -3015 |
PE-F300 -3015 |
PE-F500-3015 |
PE-F800 -3015 |
PE-F1000 -3015 |
PE-F2000 -3015 |
Laser Power |
200W |
300W |
500W |
800W |
1000W |
2000W |
Max. Cutting Thickness |
1~2mm |
2~3mm |
3~5mm |
6~10mm |
8~12mm |
16~20 mm |
Work table max. load |
700 KGS |
700 KGS |
800 KGS |
900 KGS |
1000 KGS |
1000KGS |
Laser Type |
Imported Fiber Laser |
|||||
Laser Technology |
Germany Technology |
|||||
Working area |
3000 x 1500 mm |
|||||
X axis Stroke |
3000 mm |
|||||
Y axis Stroke |
1500 mm |
|||||
Z axis Stroke |
150 mm |
|||||
Max. cutting speed |
12m/min (up to materials) |
|||||
Transmission way |
Imported ball screw |
|||||
Table-driven system |
Japanese Panasonic Servo motor & Driver |
|||||
Focus Method |
Dynamic Following and Automatic Adjust Focus |
|||||
Location precision |
≤±0.05 mm |
|||||
Re-location precision |
±0.02 mm |
|||||
Max. moving speed |
100m/min |
|||||
Laser wavelength |
1070nm |
|||||
Minimum line width |
≤0.1mm |
|||||
Supporting Format |
PLT, DXF, BMP, AI |
|||||
Power demand |
380V/50HZ |
|||||
Control Method |
offline movement Control |
|||||
Control software |
Perfect Laser Professional Laser Cutting Software |
|||||
Remark: We perfect laser has the ability to customize any sizes according to customers’ need.
