NITTO High Temperature Tape 973UL-S

Shantou Rongtai Packing Equipment Co., Ltd.
NITTO High Temperature Tape 973UL-S thumbnail-1
NITTO High Temperature Tape 973UL-S thumbnail-2
NITTO High Temperature Tape 973UL-S thumbnail-3
NITTO High Temperature Tape 973UL-S thumbnail-4
NITTO High Temperature Tape 973UL-S thumbnail-5
NITTO High Temperature Tape 973UL-S thumbnail-6
NITTO High Temperature Tape 973UL-S photo-1
NITTO High Temperature Tape 973UL-S photo-2
NITTO High Temperature Tape 973UL-S photo-3
NITTO High Temperature Tape 973UL-S photo-4
NITTO High Temperature Tape 973UL-S photo-5
NITTO High Temperature Tape 973UL-S photo-6
US$ 6.1 - 7 MOQ: 1 Roll
Key Specifications
Get Latest Price
Material:
PTFE
Use:
Masking
Adhesive Side:
Single Sided
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shantou /Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material PTFE
Use Masking
Adhesive Side Single Sided
Adhesive Type Hot Melt, Pressure Sensitive
Design Printing No Printing
Place of Origin Japan
Brand Name NITTO DENKO
Model Number 973UL-S

NITTO High Temperature Tape 973UL-S



Product Description



NITTO DENKO  high temperature tape is high-temperature super-tack electronic tape imported from Japan.
It’s top quality, stability and durability, a variety of model specifications. This tape is widely used in high-temperature enveloping, blanching combined equipment.



Features



It can resist higher temperature and more cold than common tape. In continuous use, the temperature range is -100-260 degrees Celsius, melting point up to 327 degrees, low friction, and good lubricity; on the high voltage insulator with good effect; on the chemicals or solvents not Chemical reaction; and has anti-light, anti-oxidation effect; good stickiness. Other features are wear-resisting, anti-pressure, anti-erosive, anti-microwave, high temperature resistant, anti-rubbing, slippery, sticking firmly, and shapely grain.


Brand: NITTO DENKO
Origin: Japan


Model Specifications:

NO.973UL-S  T0.13mm * W13mm * L10m              250 rolls / carton box
NO.973UL-S  T0.13mm * W19mm * L10m              250 rolls / carton box ;
NO.973UL-S  T0.13mm * W25mm * L10m              250 rolls / carton box
NO.973UL-S  T0.13mm * W38mm * L10m              125 rolls / carton box ;
NO.973UL-S  T0.13mm * W50mm * L10m              125 rolls / carton box



NO.973UL-S  T0.13mm * W300mm * L10m
NO.973UL-S  T0.13mm * W600mm * L10m



General Properties:



Item

Unit

No.973UL-S

No.973UL

Test Method

Thickness

mm

0.13

0.15

0.18

Compatible with JIS C 2107

Tensile strength

N/19mm

240

590

530

Adhesive strength

25°C

N/19mm

6.8

9.0

9.7

100°C

3.2

3.9

4.7

150°C

2.2

2.6

3.0

Unwinding force

N/19mm

5.9

5.9

7.5

Temperature range

°C

-60~260







Specification:



Model

color

Specification

Short-term heat resistance

(℃)

Continuous use temperature(℃)

Thickness (mm)

Width(mm)

Length (m)

No.973UL-S

Beige

0.13

10

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

13

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

15

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

19

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

25

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

38

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

50

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

75

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

100

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

300

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

600

10

300℃

-60~260℃

No.973UL

Beige

0.18

19

10

300℃

-60~260℃

No.973UL

Beige

0.18

25

10

300℃

-60~260℃

No.973UL

Beige

0.18

50

10

300℃

-60~260℃





Application



hot resistant, shelter; heat seal; heat electrical insulation;

Widely used in the pharmaceutical industry, food industry, printing industry, industrial, chemical and other fields.

The product is mainly used for bag sealing machine.
