973UL-S T0.13mm*W50mm*L10m Nitto Tape

Shantou Rongtai Packing Equipment Co., Ltd.
973UL-S T0.13mm*W50mm*L10m Nitto Tape thumbnail-1
973UL-S T0.13mm*W50mm*L10m Nitto Tape thumbnail-2
973UL-S T0.13mm*W50mm*L10m Nitto Tape thumbnail-3
973UL-S T0.13mm*W50mm*L10m Nitto Tape thumbnail-4
973UL-S T0.13mm*W50mm*L10m Nitto Tape thumbnail-5
973UL-S T0.13mm*W50mm*L10m Nitto Tape thumbnail-6
973UL-S T0.13mm*W50mm*L10m Nitto Tape photo-1
973UL-S T0.13mm*W50mm*L10m Nitto Tape photo-2
973UL-S T0.13mm*W50mm*L10m Nitto Tape photo-3
973UL-S T0.13mm*W50mm*L10m Nitto Tape photo-4
973UL-S T0.13mm*W50mm*L10m Nitto Tape photo-5
973UL-S T0.13mm*W50mm*L10m Nitto Tape photo-6
US$ 17.5 - 19 MOQ: 1 Roll
Key Specifications
Get Latest Price
Material:
PTFE
Use:
Masking
Adhesive Side:
Single Sided
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shantou / Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material PTFE
Use Masking
Adhesive Side Single Sided
Adhesive Type Hot Melt, Pressure Sensitive
Design Printing No Printing
Place of Origin Japan
Brand Name NITTO DENKO
Model Number NO.973UL-S

973UL-S  T0.13mm*W50mm*L10m Nitto Tape





Product Description



NITTO Tape 973UL-S  high temperature tape is high-temperature super-tack electronic tape imported from Japan.

It’s top quality, stability and durability, a variety of model specifications. This tape is widely used in high-temperature enveloping, blanching combined equipment.



Features



973UL-S Nitto Tape can resist higher temperature and more cold than common tape. In continuous use, the temperature range is -100-260 degrees Celsius, melting point up to 327 degrees, low friction, and good lubricity; on the high voltage insulator with good effect; on the chemicals or solvents not Chemical reaction; and has anti-light, anti-oxidation effect; good stickiness. Other features are wear-resisting, anti-pressure, anti-erosive, anti-microwave, high temperature resistant, anti-rubbing, slippery, sticking firmly, and shapely grain.


Brand: NITTO DENKO
Origin: Japan


Model Specifications:
NO.973UL-S  T0.13mm * W13mm * L10m  250 rolls / carton box;
NO.973UL-S  T0.13mm * W19mm * L10m  250 rolls / carton box;
NO.973UL-S  T0.13mm * W25mm * L10m  250 rolls / carton box;
NO.973UL-S  T0.13mm * W38mm * L10m  125 rolls / carton box;
NO.973UL-S  T0.13mm * W50mm * L10m  125 rolls / carton box.



General Properties:



Item

Unit

No.973UL-S

No.973UL

Test Method

Thickness

mm

0.13

0.15

0.18

Compatible with JIS C 2107

Tensile strength

N/19mm

240

590

530

Adhesive strength

25°C

N/19mm

6.8

9.0

9.7

100°C

3.2

3.9

4.7

150°C

2.2

2.6

3.0

Unwinding force

N/19mm

5.9

5.9

7.5

Temperature range

°C

-60~260







Specification:



Model

color

Specification

Short-term heat resistance

(℃)

Continuous use temperature(℃)

Thickness (mm)

Width(mm)

Length (m)

No.973UL-S

Beige

0.13

10

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

13

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

15

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

19

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

25

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

38

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

50

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

75

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

100

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

300

10

300℃

-60~260℃

No.973UL-S

Beige

0.13

600

10

300℃

-60~260℃

No.973UL

Beige

0.18

19

10

300℃

-60~260℃

No.973UL

Beige

0.18

25

10

300℃

-60~260℃

No.973UL

Beige

0.18

50

10

300℃

-60~260℃







Stickiness attribute: Silicone

Long-term temperature resistant: -60~280℃ , short-term temperature resistant: -50/300 ° C,
Tensile strength: (n / cm) 135-150;
Adhesion: (n/25mm)> 6.5,



Application



hot resistant, shelter; heat seal; heat electrical insulation;

Widely used in the pharmaceutical industry, food industry, printing industry, industrial, chemical and other fields.

973UL-S Nitto Tape is mainly used for bag sealing machine.
