Single Grind Gauge
About the Single Grind Gauge↓
Be applied to:
Single Grind Gauge is used to testing those disperse product in the process of production, storage and application of fineness of detection.
Such as applied to: paint, plastic, paint, printing ink, paper, ceramics, medicine, food, etc.
Why use Grind Gauge?
1) Grinding costs a lot - use fineness board can determine the minimum milling time, to save costs.
2) Lack of grinding materials will produce irregular film, which mean it will fail the standard value of gloss value.
3) Could compare different sources of grinding paint in the same time .
4) To optimize the grinding device.
Type And Specification:
Model Number |
Groove Size (L×W) |
Measure Range |
Block Size |
Scale Value |
Display Unit |
Groove quantity |
|
|
Single Groove Fineness grind gauge |
BGD 241/1
|
150×12.5mm |
0-25µm |
175×50×12mm |
2.5µm |
Microns or Hegman(H) |
1 PCS |
|
BGD 241/2
|
0-50µm |
175×50×12mm |
5µm |
Microns or Hegman(H) |
1 PCS |
||
|
BGD 241/3
|
0-100µm |
175×50×12mm |
10µm |
Microns or Hegman(H) |
1PCS |
||
Ordering information: BGD 241 - big scraper (suitable for BGD 242, BGD 243, BGD 243)
Material :high wear-resisting corrosion resistance of stainless steel (standard configuration a scraper)
