Help CenterHigh Speed Cutting Machine for Leather Products
Related Products
-
Automatic Cutting for Custom Motorcycle Racing Suits & One-Piece LeathersNegotiableMOQ: 1 Set -
IECHO Car Seat Covers LeatherNegotiableMOQ: 1 Set
-
Leather-Cutting Systems for Leather Sofa Leather FurnitureNegotiableMOQ: 1 Set
-
Digital Cutting Machine for Automotive Interior PU Leather Foam PVC CuttingNegotiableMOQ: 1 Set
-
Leather-Cutting Systems for Leather Sofa Leather FurnitureNegotiableMOQ: 1 Set
ECHO Leather Products digital designing and production solution
1. ECHO supplies the total solution to design and manufacture leather products, such as shoes, luggages,apparel, handbag,sofa, optimizes the production process, making all links including leather purchasing, skin inspection, classification, order management, marking to cutting close layout and co-ordination, it not only reflects the excellent plant production style, but also enhances the efficiency of the production, saves production cost and improves their market competitiveness.
2. ECHO Products run through the flows of design-marking-cutting of leather products and optimize the best of every process.
in the design process, ECHO CAD system and the digitizer can help you to design and input 2D and 3D graphics more conveniently.
in the marking process, pattern data can be imported to ECHO super automacit marking system directly.
In the cutting process, ECHO high resolution digital cutting system can help you with fast, efficient, high-precision sampling and production
.
.
3. Tool Heads
It can combine three tool heads at optional with full set of modular design cutting head, realize one completion on various cutting technical requirements for single material
Knives:
Various tool heads can be equipped with multiple series of knives, such as oscillating knife, creasing knife, drilling tool, rotary knife, tangent knife, V-Cut knife, punching knife, and appropriate knives, and the knives can be configured with different diameters and angles according to the material cutting needs.
Motor depth control:
4. With Servo motor tool depth control, it reduces the abrasion of cutting tool and enhances the cutting quality at the same time, realizes the international advanced two-stage knife raising and falling control mode, reduce the cutting time greatly, and improves production efficiency.
Imported spare parts:
5. With imported spare parts, for example, the global leading Swiss Maxon Motor, it ensures the machine run stably for long time of more than 300 hours continuously, working life is over 20 years.
Effective Cutting Area:800mm*1300mm, 1700mm*1300mm,2500mm*1600mm,2500mm*3200mm, and the size can be customerized.
Application:
Cutting car pillow, car cushion, car seat cover, steering wheel cover and other automotive interior products.
Parameters
Max Speed |
1800mm/s |
Accuracy |
0.1mm |
Max Thickness |
25mm |
Data Format |
DXF,HPGL |
Interface |
Interent |
Driver |
Servo Motor |
Media |
Vacuum System |
Power |
220V/50HZ 380V/50HZ |
Environment |
Temperature0°C-40°C |
