KX II-470 Rigid box liner paper gluing forming machine
This machine is used to fix and agglutinate bottom of the glued outer paste paper with paste inner mount board,and agglutinate around plane and pack it's angle.
Features:
Shinnied electrial equipment
Imported brake clutch
Imported inverter
Advanced flexible shatft control for angle wrap
Automatic or semi- automatic choosing box forming control
Ajustable frequency - converting control device
Rubber roller for box pasting
Speed digital display control device
Automatic counting device
Adjustable length and width of chrome- plated for mount printing equipment
Main Specifications:
Power |
1.5kw |
Max.Width |
450 X 350 X 110 (mm) |
Min. Width |
120 X 80 X 10 (mm) |
Overall Dimensions |
1300 X 1000 X 2800 (mm) |
Overall Weight |
450kg |
Max Speed |
15-30times/min |
Voltage |
220V/50Hz |
