Specifications
6520 fish paperIt has excellent electrical and mechanical properties, has been sold over 20 country.good insulation product.
6520 fish paper
It is a two-ply flexible insulation materials consisting of fish paper and polyester film(raw material of polyester film used thickness 0.036mm).the used adhesive is acid-free and temperature resistant,it has excellent electrical and mechanical properties,it can be used for low-voltage motors,electrical insulation in a groove,insulation and cushioning interterm insulation.
It enables easy processing on automatic machines.
It can be used as slot and phase insulation in low voltage machines of as interlayer insulation in transformers.
Products can be supplied in rolls ,sheet,tapes or shapes according to customer requests.
Hot-resistant:120°c grade E insulation
Availiable thickness:0.13 0.15 0.17 0.20 0.25 0.30 0.35mm
Breadth:1000mm
Number |
Index |
Unit |
Standard |
Test Result |
|
1 |
Norminal thickness |
mm |
0.25±0.030 |
0.25 |
|
2 |
Norminal Grammage |
g/m2 |
300±45 |
310 |
|
3 |
Tensile Strength |
MD(no bending) MD(after bending) CD(no bending) CD(after bending) |
N/10mm |
≥210 ≥130 ≥110 ≥80 |
220 160 140 90 |
4 |
Elongation |
MD(no bending) CD(no bending) |
% |
≥3 ≥10 |
6 15 |
5 |
Breakdown Voltage |
KV |
≥6.0 |
7.5 |
|
6 |
Average Coherence |
/ |
No delamination |
Approval |
|
7 |
Thermal Coherence(120±2)°C10Mintues |
/ |
No blister,nodelamination,no adhensive flow |
Approval |
|
