Pistol mounted IR laser sight and 200 lumen CREE Q5 LED light combo with strobe function

Specifications

IR laser sight and led light combo
1.IR laser sight 830nm, 30mw with night visision device
2.200 lm led light
3. Hard anodize

Model: ES-XL-2LL-IR-H



Name: Weapon-mounted Tactical XL-2LL-IR-H LED Llight and Infrared laser sight Combo,  IR laser sight, IR laser sight or infrared laser scope and LED light combo, laser sight, led light with strobe function

Product Origin: China

Supply Ability: 1000 pcs/month

Minimum Order: 100 pcs

Delivery Lead Time for MOQ: 20 days







TECHNICAL DESCRIPTION
Wavelength: 830nm
Power Output: <30mW
Laser Type (mw): 30
Battery: Two CR123 Lithium Batteries
Battery Life: 2.5 hours of runtime
Lamp cup radiation angel: 45 degree

LED detailed information
LED model: CREE Q5 LED-003
Power: 3W
Diameter: Ø 8 mm
Length: 85 mm
LED brightness: Up to 200 or 225 lumens blinding beam, Bright sidelight
LED radiation angel: 120 degree
Light color: Cold white
Max electric current: 750mA
Working Temperature:-40 ~ +85
Light attenuation: Less than 3% after 100k hours
Life time: ≤ 50000 hours

Laser detailed information
Model: D-1250
Lense material: Optical glass
Laser dot shape: Oval
Laser dot size: ≤5mm at 25m
Luminous exitance: ≤0.2 mard
Laser scope housing size: 12X40 mm
Working Temperature:-10 ~ +50
Storage Temperature:-20 ~ +65
Max voltage: DC 3-5V
Max electric current: ≤180mA
Life time: ≥ 5000 hours
Working volt: 3V

Weight with Battery: 4.72 oz, 133.8g
Warranty: Extended Warranty
Construction: Aircraft aluminum 7061-T6
Finish: Anodic oxidation/ V'r 3 black
Operation: Ambidextrous Momentary/Steady on-off Switch
Rail Mount: Integrated mount

KIT INCLUDES
Infarared Laser sight and LED Flashlight integrated combo
Calibration tools
2 CR-123A lithium batteries
User manual

PACKING
Packing: 1 unit/gift box, 50 units/master carton
Unit package: Gift box paper box
Inner carton and Master Carton: Top cardboard carton

FEATURES
Quick target acquisition
Lightweight
Compact
Safe and adjustable
Dust and Shockproof
Ambidextrous Momentary/Steady on-off Switch
Machined anodized aluminum housing
Fits existing light bearing holsters
Adjustable mount flexibility that can accommodate the Glock or Picatinny (1913) accessory rails.

IR LASER SCOPE ZEROING
For a laser mounted below or to the side of the bore, there is only one distance where the bullet path will coincide with the laser sight line, this point is the "zero range".
Laser adjustment and the muzzle velocity of the bullet determine where this point occurs. The user must decide how high above or below the sight line the bullet can be allowed to strike and adjust the sight accordingly. At distances less than the zero range the bullet will be above the sight line. Beyond the zero range the bullet will be the sight line.
If mounted to the side, the bullet will also deviate to the side of the laser line, as well as up and down. In practice, a XL-2LL on a handgun can be adjusted to keep the bullet strike within about "2 high and 2 low" out to about 100 feet.

BATTERY ASSEMBLY
The ES-XL-2LL Infrared laser scope uses 2 CR-123 (6V) batteries. The CR-123's negative and positive pole has been indicated on the mount.

DANGER: DO NOT use anything other than a CR-123 battery or rechargeable batteries with this product.

To access the battery compartment you must first remove the flashlight from the firearm. Follow the XL removal procedure instructions to remove the flashlight from the firearm.

1.Unclip the door latch, the latch is tight, it may help to use a coin.
2.Slip the batteries from the flashlight.
3.Insert the new batteries observing polarity. Note: The flashlight is polarity protected and will not light if the batteries are inserted incorrectly.
4.Hold the battery switch/door at an angle and place the small tab on the bottom of the battery/door switch into the slot in the flashlight body.
5.Firmly push and hold the door closed against the flashlight body.
6.Swing the door latch over the door and snap it into place.

WARNING / CAUTION
NEVER point the laser directly at or into an eye. This may cause damage to the eye or blindness.
When zeroing the laser follow all standard firearm safety precautions.
If the laser sight is used on different weapons then zero adjustment may again be required.
The laser sight has an anti-shock design, but a serious blow to the laser, the weapon or rail may require-zeroing.
Don not attempt to open or modify the laser cartridge





MOUNTING/REMOVAL PROCESURE

Make sure that the firearm is unloaded and the breech is open. It is imperative that safety measures by employed at all times while handling the firearm.







1. The XL is design to be quickly attached or detached from the side of the weapon or accessory rail.

2. Loosen the rail clamp tension bolt.

3. Angle the XL, placing the fixed portion of the rail clamp against the accessory rail and align the rail key with the appropriate cross groove in the accessory rail.

4. Slightly depress the tension bolt to open the rail lamp, rotate the XL into place and release the pressure on the tension bolt to snap the light in place.

5. Check for fit and tighten tension bolt until the XL is securely attached to the firearm.



MAINTENACE

The XL rail clamp tensioning bolt requires an application of high quality gun oil to keep it rust free. Use a soft cloth and mild detergent to clean the glass LED lens and keep it free of dirt and grime. The laser aperture (XL-2LL) can be cleaned with a Q-tip 9or similar item) and mild detergent.

Note: always avoid aggressive cleaning solutions as they may damage the XL.





XL PARTS

Note: The XL rail key can be changed to accommodate several varieties of mounting rails. Remove the rail key screw with a 7/64^th hex wrench and pull the rail key from the body. Insert the new rail key and fasten it in place with the rail key screw.

....
