UTV Electric Winch 12V ATV Winch 3500lb 4000lb 4500lb WIN3500A01

Name: UTV Electric Winch 12V ATV Winch 3500lb 4000lb 4500lb WIN3500A01
Brand: powerlife
SKU: 143838086
Availability: InStock

Negotiable MOQ: 100 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

powerlife

Model Number:

WIN3500A01

Hutz Auto & Air Nanjing Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name powerlife

Model Number WIN3500A01

Power Source Electric

Application ATV/UTV

Capacity 3500lbs

Electric Winch - UTV Series

visit for more information;
visit /UTV-electric-winch.html for more information;
contact sales(at) for more information;

Basic series

Model	WIN3500A01	WIN4500A02W
Rated line pulling	3,500 lb/ 1,587 kg	4,500 lb/ 2,041 kg
Power input	1.2hp/0.9kw/12V DC	2hp/1.5kw/12V/24V DC
Motor	permanent magnetic	permanent magnetic
Control	in-line switch with control box	in-line ATV switch plus wireless remote
Gear train	3 stage plantary	3 stage plantary
Gear ratio	153:1	185:1
Clutch	manual slide	sliding ring gear
Braking action	mechanical	automatic in the drum
Drum dimension	Φ37 x 74 mm	Φ52 x 79 mm
Cable or Rope	Φ5.8mmx9.2m steel	Φ6.5mmx10m steel
Fairlead	4-way roller fairlead	4-way roller fairlead
Accessories	mount plate	Mount plate
N.W	6.5 kg	12 kg

Speedy series

Model	WIN3500A03S	WIN3500A03SR	WIN4000A01S	WIN4500A02SW
Rated line pulling	3,500 lb/ 1,587 kg	3,500 lb/ 1,587 kg	4,000 lb/ 1,814 kg	4,500 lb/ 2,041 kg
Power input	1.1hp/0.8kw/12V DC	1.1hp/0.8kw/12V DC	1.2hp/0.9kw/12V DC	2hp/1.5kw/12V/24V DC
Motor	permanent magnetic	permanent magnetic	permanent magnetic	permanent magnetic
Control	in-line ATV switch with control box	in-line ATV switch with control box	in-line ATV switch with control box	in-line ATV switch plus wireless remote
Gear train	3 stage plantary	3 stage plantary	3 stage plantary	3 stage plantary
Gear ratio	128:1	128:1	136:1	136:1
Clutch	keyway cam	keyway cam	sliding ring gear	sliding ring gear
Braking action	automatic in the drum	automatic in the drum	automatic in the drum	automatic in the drum
Drum dimension	Φ45 x 81 mm	Φ45 x 81 mm	Φ50 x 74 mm	Φ52 x 79 mm
Cable or Rope	Φ5.4mmx15m steel	Φ6.0mmx14m synthetic	Φ5.8mmx9.2m steel	Φ6.5mmx10m steel
Fairlead	4-way roller fairlead	2-way fairlead	4-way roller fairlead	4-way roller fairlead
Accessories	mount plate	mount plate	mount plate	Mount plate
N.W	12 kg	10 kg	15 kg	12 kg
