Home > Products > Truck Scale > SCS truck weighbridge scale 60T
SCS truck weighbridge scale 60T
- 10 Set / Sets per Month
- Tianjin Port China
- T/T Credit Card
Product Details
| Place of Origin: | Hebei, China | Brand Name: | TOPS | Model Number: | SCS |
| Type: | Truck Scale | Power Supply: | AC 220/50HZ | Display Type: | LED |
| Rated Load: | 200MT | Accuracy: | 5kg-20kg |
Product Description
SCS truck weighbridge scale 60T
Product Description
SCS series electronic digital truck scale is a new generation truck scale which depends on dimastic truck scale advantage.
The truck scale is made of U-Shape beams and channel steel,and splices them together into the closed box-type structure,which is a very strong structure.
The welding process adopts advanced welding technology,effectively ensure the flatness and non-deformation of such a large weighing platform,geometrical size and rational distribution of welding stress.
Installation Method: under-ground, up-ground
Model Number | Capacity (ton) | Size of Platform (m) | Sections | Value of Scale Division |
SCS-20 | 20 | 3x7 | 4 | 10 |
SCS- (30-60) | 30-60 | 3x7, 3x8 | 4 | 10 |
SCS- (60-80) | 60-80 | 3x9, 3x10, 3x12, 3x14 | 4 | 20 |
SCS- (80-100) | 80-100 | 3x14, 3x16 | 8 | 50 |
SCS- (100-120) | 100-120 | 3x16, 3x18, 3.3x16, 3.3x18 | 10 | 50 |
SCS- (120-150) | 120-150 | 3x18, 3x20, 3.3x18, 3.3x20 | 10 | 50 |
SCS- (150-200) | 150 | 3.3x18, 3.3x20, 3.3x24 | 10 | 50 |
Packing : The body of truck scale is nude packed and the accessories part are packed in carton.Install in 20' FCL or 40' GP .
Product Pictures:
Truck Scale
Platform Weighing Scale for grain
Sale Portable Axle Truck Scale to Romania
Sale 3mX8m SCS-60T Truck Weighing Bridge to Mauritius
Our products has exported to Romania,Kenya,Pakistan,Mauritius,South Africa,etc.
If any interested,pls do not hesitate to contact me.
