150-180 TPH Quarry Crusher Plant Price

150-180 TPH Quarry Crusher Plant Price thumbnail-1
150-180 TPH Quarry Crusher Plant Price photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, stone production line
Application:
Granite, Basalt, Marble, Quartz, Aggregate, Quarry, Coper ore, Iron ore,Concrete, Marble, etc.
Contact Supplier Request Quote Chat Now
Zhengzhou Unique Industrial Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao; Shanghai; Tianjin etc.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, stone production line
Application Granite, Basalt, Marble, Quartz, Aggregate, Quarry, Coper ore, Iron ore,Concrete, Marble, etc.
Motor Type AC Motor
Power(W) 440 KW
Capacity(t/h) 150-180
Place of Origin Henan, China
Brand Name UNIQUE
Certification ISO
Warranty More than 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Quarry Crusher Plant Price
1. Professional configuration
2. High Crushing ratio
3. Low dust
4. Less wear parts

150-180 TPH  Quarry Crusher Plant Price

150-180 TPH Quarry Crusher Plant Price



Introduction of 150-180T/H Quarry Crusher Plant
1.Mainly applied to medium or over-hard ores and stones
2.Primary jaw crusher is equipped with enhanced jaw plates and has high reduction ratio. Main frame and flywheels use thicker steel plate; We apply impact crusher as the secondary crusher
4.Water pipe or other washing equipments are equipped to clean the finished products
5.Tertiary crusher(VSI )sand making machine or others may work as additional processing machines to diversify the final products. Tailor-made dust catcher or dust cover can also be applied to this plant

150-180 TPH Quarry Crusher Plant Price

Main Units of 150~180T/H Quarry Crusher Plant

Vibrating Feeder  Jaw Crusher  Impact Crusher  Vibrating Screen  Auxiliaries
 		 Control systm



ZSW 490 x110
Max Feeding Size: ≤630mm
Power: 15 kw


PE-750 X 1060
Max Feeding Size: ≤630mm
Power: 110kw

PF-1315
Max Feeding Size: ≤500mm
Power: 220kw



3YK1854
Sep1=40mm  Sep2=20mm  Sep3=5mm
Power: 22kw

Belt Conveyor
B800 X 17M
B800 X 20M
B500 x 22M
B500 X 16M
B500 X 16M
B500 X 16M

Electronic Control Cabinet

150-180 TPH Quarry Crusher Plant Price

Zhengzhou Unique Industrial Equipment Co., Ltd, a reliable and professional supplier of Quarrry Crusher Plant

This production line calls for medium investment, you always get much more than you pay, it is the ideal choice for the clients.

Aggregate Plant 150~180T/H



Introduction of 150~180T/H Aggregate Plant:

In comparison with 100-120TPH rock crushing plant, 150TPH-180TPH rock crushing line is more competent when processing medium or over hard ores, especially while it is used for producing big aggregate.
All the machines applied in this production line work together and form a circle flow production line, which improve the efficiency and make the central control easier.
The primary jaw crusher PE750X1060 equips with stronger, enhanced jaw plates and larger feed opening, which increases the reduction ratio. In addition, thicker steel plate has been applied to main frame and flywheels, while the diameter of the flywheels are enlarged that greatly increased the weight of the machine, so when it works, the vibration is very slight but the crushing kinetic energy is very forceful.
The secondary crusher we use is impact crusher which is widely used and welcomed by users in lots of countries due to its high working efficiency.
For the purpose of improving finished products’ quality, water pipe or other washing equipments can be equipped upon filtrating equipments to clean the finished products.
Tertiary crusher such as VSI or others may work as additional processing machines to diversify the final products. Tailor-made dust catcher or dust cover can also be applied to this plant.
This production line calls for medium investment, you always get much more than you pay, it is the ideal choice for the clients.



Main Components of 150~180T/H Aggregate Plant:



Vibrating Feeder ZSW 490 x110

Max Feeding Size: ≤630mm

Power: 15 kw



Jaw Crusher PE-750 X 1060

Max Feeding Size: ≤630mm

Power: 110kw



Impact Crusher PF-1315

Max Feeding Size: ≤500mm

Power: 220kw



Vibrating Screen 3YK1854

Sep1=40mm  Sep2=20mm  Sep3=5mm

Power: 22kw



Auxiliary Components:

Belt Conveyor

B800 X 17M

B800 X 20M

B500 x 22M

B500 X 16M

B500 X 16M

B500 X 16M



Control system

Electronic Control Cabinet
