China Patent Product Strong Force Impact Crusher for Concrete Crushing & Recycling
Introduction
PJ strong vortex impact crusher is designed by our many year’s production experience, absorbing the advanced technology, combined with the relevant industry and mining conditions,. The equipment is mainly used for crushing concrete, block and other type construction waste.
Difference between common PF impact crusher & PJ Strong Force Impact Crusher
Features:
1. "Stone on stone " crushing, reducing friction and small power consumption;
2. large broken ratio, small final product size;
3. It is convenience to adjust for impact plate and hammer head distance, and the discharge range is adjustment between 3mm and 30mm;
4. It can save 40% electricity than third-class crushing;
5. Discharge grid plate can adjust out of the machine;
Working pricinple:
Design with particular vortex crushing chamber and three chambers of curved surface; the interval between tooth liner and plate hammer in the medium and fine crushing chamber is adjustable, so the discharging size can be effectively controlled; the high wear-resistance plate hammer adopts plug-in installation; the multi-azimuth doors of frame, screw rod or hydraulic opening device make the wearing parts replacement and the maintenance more easier.
Technology Parameter:
Models |
Max. feed size(mm) |
Discharge size (mm) |
Capacity (t/h) |
Motor (kw) |
Dinebsions (mm) |
|
| -150MPa | -250MPa | |||||
| PJ0808 | 200 | 150 | -25 (80-90%) | ~46 |
~55 | 1900×1860×2150 |
| PJ1108 | 300 | 180 | -30 (80-90%) | ~80 | ~90 | 2845×2148×2262 |
| PJ1110 | 400 | 200 | -35 (80-90%) | ~112 | ~110 | 2845×2360×2262 |
| PJ1113 | 400 | 200 | -40 (80-90%) | ~150 | ~132 | 2845×2719×2262 |
| PJ1310 | 500 | 250 | -40 (80-90%) | ~180 | ~160 | 3913×2511×2925 |
| PJ1313 | 600 | 250 | -40 (80-90%) | ~225 | ~220 | 3913×2719×2925 |
| PJ1315 | 700 | 300 | -50 (80-90%) | ~280 | ~280 | 3913×2969×2925 |
| PJ1320 | 700 | 300 | -50 (80-90%) | ~350 | ~400 | 3913×3402×2925 |
| PJ1515 | 1000 | 350 | -50 (80-90%) | ~400 | ~400 | 4310×3330×3660 |
| PJ1520 | 1000 | 400 | -50 (80-90%) | ~500 | ~550 | 4310×3330×3660 |
Strong Force Impact Crusher Applied in Mobile Waste Concrete Crushing Plant
