Specifications
QTZ63B(5013) Tower Crane Electric Parts1.Hydraulic self-raised Tower crane
2.ISO/CCC/CE Certification
3.High Quality
QTZ63B Tower Crane Electric Parts
Introduction of our Tower Crane Electric Parts :
Our Tower Crane is characterized by horizontal jib frame, trolley travel, slewing self-climbing, novel structure and reliable running. All accessories are adopted from home famous brands and electrical components from international famous brands. “Quality First” is not just a slogan, which has already deeply rooted in UNIQUE people’s soul, besides we will also make all your purchases in unlimited satisfaction with our star-rated after-sales service.
Main Parameters of QTZ63B Tower Crane Electric Parts :
Model: QTZ63B (5610/5013)
Radius: 56/50M
Hook Height: 41M
Max. height: 141M
Max. hoisting Capacity: 6T
Standard Mast Section Size: 1.835x1.835 x2.5M
Hoisting Speed: 80/40/8.5r/min
Slewing Speed: 0.62r/min
Luffing Speed: 42/21m/min
| Rated Lifting Moment | 1000KN.M |
| Rated Loading Capacity | 6T |
| Max. Lifting Load | 6T |
| Tip Load | 1.3T |
| Max. Lifting Height | 120m |
| Span | 50m |
| Free standing height | 40m |
| Rope length | 400m |
| Slewing speed | 0.6r/min |
| Power supply | 380V/50Hz |
| Power Capacity | 42.3Kw |
| Electric switch box | Schneider |
| Working range | 2.5-50m |
| Trolleying speed | 20/40 m/min |
| Jacking up speed | 0.55m/min |
| Topkit height | 6.2m |
| Counter jib length | 13m |
| Mast section | 1.6*1.6*2.5m |
| Main material | ∠135*10 mm(square steel) |
| Hoisting speed |
(a=2) 80/40/8.5m/min ; (a=4) 40/20/4.25m/min |
