Double Cages SS100/100 Electric Construction Material Hoist

Specifications

SS100/100 Electric Construction Material Hoist
1.High Security
2.Advanced control performance
3.Reliable,durable,easy

SS100/100 Electric Construction Material Hoist



1. Double cages work independently, using two winches transmission, safe and reliable, more productive.

2. Structural strengthening, head of standard sections with seamless steel pipe, section dimensions 1.2*0.87m

3. SS100/100 products equivalent to the equipment of SS120 series construction hoist.

SS dual cages series construction hoist has the following characteristics:

1. Novel structure, double cages work independently, high work efficiency.

The machine is a dual cage working independently, two hosts can be operated by one person. Working performance is more than twice times as efficient as conventional gantry hoist.

2. Strong security, prevention was made, and fall prevention device equipped with advanced, risk falling phenomenon does not occur.

The hoist is equipped with a discharge was made, fall protection and upper and lower device, equipped with a parachute on a hoist equipment, unexpected break for wire rope hoists safe and secure when docked on the standard section.

3. Long working life, occupied by small, easy to install.

The hoist is with name brand winch, long service life, single column double cage occupied by small, convenient installation, high production efficiency.



Technical Parameter of SS100/100 Electric Construction Material Hoist
Item		Unit	Parameter
Basic Installation Height		m	24
Attachment Installation Height		m	80
Rated Lifting Capacity		Kg	1000/1000
Lifting Speed		m/min	23.5
Cage Dimension (L*W*H)		m	3*1.3*12.4
Sectional Dimension Of Bracket		m	0.8*0.8
Motor Power		Kw	Single-cage 11.5 Double-cage 23
Steel Rope Model			6*37+1-12-170-Right
Steel Rope Length(Typical)		m	75
Total Weight	Single-cage (at 24m)	Kg	3260
	Double-cage (at 24m)	Kg	4850

  Mast Section:



Winches:



Customer Visit:
