2013 Widely Used JS750 Concrete Mixing Machines For Sale

Specifications

JS750 Concrete Mixing Machines:
1.High efficiency
2.Easy to maintain and replace
3.Good homogeneity
4.Twin shaft mixer

JS750 Concrete Mixing Machines



Description of JS750 Concrete Mixing Machines :
JS500-1500 Concrete Mixer developed by our company is widely used by our global users. This machine can be used as a separated mixing machine or used as the supporting machine of the ready mix concrete plant. When matched with batching plant, they can form a simple mixing plant.



Features of JS750  Concrete Mixing Machines :
1. As a miniature double-horizontal-shaft forced type concrete mixer, this concrete mixing machine features short mixing time, good homogeneity and reliable operation.
2. Shaft tip is sealed by floating-ring, which is reliable and easy to maintain and replace.



Application of JS750 Concrete Mixing Machines :
This concrete mixer can be used to mix stiff-consistency concrete, semi-stiff-consistency concrete, light weight aggregate concrete and so on.



Technical Specification of JS750  Concrete Mixing Machines :

Model: JS750

Discharge volume: 750L

Charging volume: 1200L

Theoretical capacity: ≥35m³

Aggregate sizes: ≤60/80m

Working circle: 60s

Mixing blade

Speed: 30.5r/min

Quantity: 2×8

Mixing motor

Model: Y200L-4

Power: 30 kw

Lifting motor

Model: YEZ132M-4

Power: 7.5 kw

Pump motor

Model: 65DWB35-5

Power: 1.1 kw

Weight: 6150kg

Dimensions (L x W x H): 4550x2250x2450 mm



Parameter Model		JS500	JS750	JS1000	JS1500
Item
Discharge volume		500L	750L	1000L	1500L
Charging volume		800L	1200L	1600L	2400L
Theoretical capacity		≥25m3	≥35m3	≥50m3	≥75m3
Aggregate sizes		≤60/80mm	≤60/80m	≤60/80mm	≤60/80mm
Working circle		60s	60s	60s	60s
Mixing blade	Speed	35r/min	30.5r/min	25.5r/min	23r/min
	Quantity	2×7	2×8	2×8	2×9
Mixing motor	Model	Y180M-4	Y200L-4	Y225S-4	Y225M-4
	Power	18.5 kw	30 kw	37 kw	45 kw
Lifting motor	Model	YEZ132S-4	YEZ132M-4	YEZ160L-4	YZE180M-4
	Power	5.5 kw	7.5 kw	11 kw	18.5 kw
Pump motor	Model	50DWB20-8A	65DWB35-5	KQW65-100	KQW65-100
	Power	0.75 kw	1.1 kw	3 kw	3 kw
Weight		1500kg	6150kg	9880kg	10960kg
Dimensions (L x W x H)		3030x2300x2680 mm	4550x2250x2450 mm	4640x2250x2250 mm	5058x2250x2440 mm
