Specifications
JS1000 Concrete Mixer Capacity:1.Short mixing time
2.Reliable structure
3.Low price and noise
4.Easy operation
JS1000 Concrete Mixer Capacity
Description of JS1000 Concrete Mixer Capacity :
JS500-1500 Concrete Mixer developed by our company is widely used by our global users. This machine can be used as a separated mixing machine or used as the supporting machine of the ready mix concrete plant. When matched with batching plant, they can form a simple mixing plant.
Features of JS1000 Concrete Mixer Capacity :
1. As a miniature double-horizontal-shaft forced type concrete mixer, this concrete mixing machine features short mixing time, good homogeneity and reliable operation.
2. Shaft tip is sealed by floating-ring, which is reliable and easy to maintain and replace.
Application of JS1000 Concrete Mixer Capacity :
This concrete mixer can be used to mix stiff-consistency concrete, semi-stiff-consistency concrete, light weight aggregate concrete and so on.
Technical Specification of JS1000 Concrete Mixer Capacity :
Model: JS1000
Discharge volume: 1000L
Charging volume: 1600L
Theoretical capacity: ≥50m3
Aggregate sizes: ≤60/80mm
Working circle: 60s
Mixing blade
Speed: 25.5r/min
Quantity: 2×8
Mixing motor
Model: Y225S-4
Power: 37 kw
Lifting motor
Model: YEZ160L-4
Power: 11 kw
Pump motor
Model: KQW65-100
Power: 3 kw
Weight: 9880kg
Dimensions (L x W x H): 4640x2250x2250 mm
Parameter Model | JS500 | JS750 | JS1000 | JS1500 | |
Item | |||||
Discharge volume | 500L | 750L | 1000L | 1500L | |
Charging volume | 800L | 1200L | 1600L | 2400L | |
Theoretical capacity | ≥25m3 | ≥35m3 | ≥50m3 | ≥75m3 | |
Aggregate sizes | ≤60/80mm | ≤60/80m | ≤60/80mm | ≤60/80mm | |
Working circle | 60s | 60s | 60s | 60s | |
Mixing blade | Speed | 35r/min | 30.5r/min | 25.5r/min | 23r/min |
Quantity | 2×7 | 2×8 | 2×8 | 2×9 | |
Mixing motor | Model | Y180M-4 | Y200L-4 | Y225S-4 | Y225M-4 |
Power | 18.5 kw | 30 kw | 37 kw | 45 kw | |
Lifting motor | Model | YEZ132S-4 | YEZ132M-4 | YEZ160L-4 | YZE180M-4 |
Power | 5.5 kw | 7.5 kw | 11 kw | 18.5 kw | |
Pump motor | Model | 50DWB20-8A | 65DWB35-5 | KQW65-100 | KQW65-100 |
Power | 0.75 kw | 1.1 kw | 3 kw | 3 kw | |
Weight | 1500kg | 6150kg | 9880kg | 10960kg | |
Dimensions (L x W x H) | 3030x2300x2680 mm | 4550x2250x2450 mm | 4640x2250x2250 mm | 5058x2250x2440 mm | |
