2013 Best Selling Portable Stone Driller Machine

Zhengzhou Unique Industrial Equipment Co., Ltd.
2013 Best Selling Portable Stone Driller Machine thumbnail-1
2013 Best Selling Portable Stone Driller Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai or other China main port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drilling Rig
Power Type Diesel
Model Number KY120
Usage Other, drilling borehole for quarry, mining and construction
Dimension(L*W*H) 5100x2030x2020mm
Weight 3.3t
Certification ISO
Warranty 15 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

portable stone driller
powerful & reliable engine
adjustable boom
reliable hydraulic system & pump sets
long life

2013 best selling portable stone driller machine



It is widely used in quarry, railway, road, water and electricity, open-pit mines and construction work site to do deep or medium-deep rock hole drilling operations. Woring with the air compressor and the impactor(DTH hammer), it can drill horizontal, vertical, inclined blast hole, pre-hole and anchor bolt holes.



Specifications of Crawler Drill KY120



Rock Rigidity: f=6-20



Dia. of hole: 80-115 mm



Optimum Drilling Depth: 25 m



Working Pressure: 1.0-1.4 Mpa



Air Consumption: ≥13m3/min.



Rotation Speed: 0-65 rpm



Torque: 1400 N•m



Lift power: 17 KN



Dimensions: 5100x2030x2020mm



Weight: 3300 kg



Drive System: YC 2108 Engine



Recommended Mobile Screw Air Compressor: LGCY-13/13





Specification of Matched Mobile Screw Air Compressor LGCY-13/13



Capacity: 13m3/min.



Working pressure: 1.3MPa



Corresponding diesel engine: Cummins 6BTA5.9-C180 (132kw)



Dimensions: 3600x1900x2200 mm



Weight: 3500 kg





2013 best selling portable stone driller machine





















2013 best selling portable stone driller machine



2013 best selling portable stone driller machine
