Home > Manufacturing & Processing Machinery > Machine Tools > Drilling Machine > Universal Drilling and Milling Machine, Table 1120x260 1270X320mm, Drill Dia 50mm, Vertical Mill Dia 25mm, End Mill Width 125mm
Universal Drilling and Milling Machine, Table 1120x260 1270X320mm, Drill Dia 50mm, Vertical Mill Dia 25mm, End Mill Width 125mm
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Model Number:
XZ6350ZS XZ6326
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Drilling and Milling Machine XZ5150, Table 1220x360mm, Drilling Dia 50mm, Vertical Milling Dia 32mm, End Milling Width 125mmNegotiableMOQ: 1 -
Drilling and Milling Machine ZAY Sery, With Dia 20 25 32 40 45 50mmNegotiableMOQ: 1
-
Drilling and Milling Machine X6332Z, Table 1320x320mm, Drilling Dia 50mm, Vertical Mill Dai 25mm, End Mill Width 125mmNegotiableMOQ: 1
-
Drilling and Milling Machine, Table 1120x260 1120X280mm, Drilling Dia 50mm, Vertical Milling Dia 25mmNegotiableMOQ: 1
-
Vertical Drilling Machine Z Sery, With Dia. 32 40 45mmNegotiableMOQ: 1
Condition
New
CNC or Not
Normal
Model Number
XZ6350ZS XZ6326
Certification
CE ISO
Specifications | Units | XZ6326 | XZ6350ZS |
Table size | mm | 1120×260 | 1270×320 |
Table travel | mm | 600×300 | 730×290 |
Distance from spindle nose to table surface | mm | 115-430 | 120-500 |
Max. drilling dia. | mm | 50 | 50 |
Automatic drilling dia. | mm | 14( cast iron) | 14(cast iron) |
Max. end milling width | mm | 125 | 125 |
Max. vertical milling dia. | mm | 25 | 25 |
Max. tapping dia. | mm | M16 | 100-430 |
Spindle speed range | rpm | 67-2010(V)/38-1310(H) | 90-2000(V)/60-1350(H) |
Spindle travel | mm | 120 | 120 |
Automatic spindle feeds | mm/rev | 0.1 0.15 0.3 | 0.1 0.15 0.3 |
Overall dimension | mm | 1580×1450×2150 | 1680×1640×2200 |
Spindle motor power | kW | 1.5/2.2 2.2 | 2.2 |
Machine weight | kg | 1350 | 1650 |
