Double-needle, Unison-feed, Lockstitch Machine With Vertical-axis Large Hook

Double-needle, Unison-feed, Lockstitch Machine With Vertical-axis Large Hook photo-1
Negotiable MOQ: 3 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Taiwan, China
Model Number:
EM-1560
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Taiwan, China
Model Number EM-1560

Specifications

Double-needle, Unison-feed, Lockstitch Machine with Vertical-axis Large Hook

♦EM- 1560 SERIES



*EM-1560            for heavy materials

*EM-1560-T         for thick thread (#0)

*EM-1560-FL      with pneumatic auto-lifter

*EM-1560H-BT    with automatic backtack and auto-lifter





FEATURES:

*With the adoption of a new rectangular feed mechanism, an alternating vertical movement

  mechanism, and a unison-feed mechanism, the machine can feed heavy materials powerfully and

  smoothly. Well tensed seams are consistently produced without pitch errors.



*The maximum stitch length is 9mm. The complete rectangular feed locus enables accurate feed of

  extra heavy materials while preventing stitch gathering.



*With its sufficient needle bar stroke of 38mm and long 190R needle, the machine supports the

  sewing of extra heavy materials.



*Automatic lubricating mechanism improves maintainability. The sub oil pan and double filter prevent

  dust from entering the oil.



*The machine is equipped as standard with a safety clutch for preventing hook breakage. Reset work

  can be done simply by pressing a button.







SPECIFICATIONS:

Max. Sewing Speed

2,000 s.p.m.

Needle

Organ DPx17 #23

Max. Stitch Length

9mm

Needle System

#20 ~ #25

Lift of the Presser Foot

9mm by Hand, 16mm by Pedal

Thread

#20 ~ #1

Alternating Vertical Movement

2.5 ~ 6.5mm

Lubrication

Automatic

Needle Gauge

4.8mm,6.4mm,7.9mm,
9.5mm,12.7mm
(3/16,1/4,5/16,3/8,1/2)

Motor

Clutch Motor, 1/2HP, 4P

Needle Bar Stroke

38mm

N.W. / G.W.

50 / 59 KGS

Working Space

255mm

Meas.

0.19 CBM
