Help CenterSuper High Flow Series Fuel Dispenser
Related Products
Specifications
Super High Flow Fuel dispenser, different models' flow rate from 90L/min to 800L/min.APPLICTATION
Oil Refinery, Storage Transportation, Petrol Station & Storage Truck, Aviation Fueling, Railway Fueling, Public Transport Department, Vessel Fueling, Corporation Oil Transportation.
Model |
Description |
|
50-90L |
Flow rate: 50-90L/min |
With ZCB-90 GEAR PUMP, MJ85-S FLOW METER, 1.1KW MOTOR, 1 HOSE, 1 AUTOMATIC NOZZLE |
90-120L |
Flow rate: 90-120L/min |
WITH YB-40 ROTARY VANE PUMP, MJ-220 FLOW METER, 2.2KW MOTOR, 1 HOSE, 1 AUTOMATIC NOZZLE. |
120-180L |
Flow rate: 120-180L/min |
WITH YB-40 ROTARY VANE PUMP, M-40-1 POSITIVE DISPLACEMENT FLOW METER, 2.2KW MOTOR, 1.2 HOSE, 1.5 NOZZLE. |
180-300L |
Flow rate: 180-300L/min |
WITH YB-65 ROTARY VANE PUMP, M-50-1 POSITIVE DISPLACEMENT FLOW METER, 2.8KW MOTOR, 2 HOSE, 2 VALVE NOZZLE. |
300-500L |
Flow rate: 300-500L/min |
WITH YB-65 ROTARY VANE PUMP, M-50-1 POSITIVE DISPLACEMENT FLOW METER, 3.7KW MOTOR, 2.5 HOSE, 2.5 VALVE NOZZLE. |
500-800L |
Flow rate: 500-800L/min |
WITH YB-80 ROTARY VANE PUMP, M-80-1 POSITIVE DISPLACEMENT FLOW METER, 5.8-7.1KW MOTOR, 3 HOSE, 3 VALVE NOZZLE. |
