100% Cotton Conveyor Belt
- shanghai
- T/T
You May Like
Product Details
| Condition | New | Material | Other, Cotton,Canvas | |
| Material Feature | Other, anti-impact | Structure | Belt Conveyor | |
| Place of Origin | Jiangsu, China | Brand Name | New Hengtong |
Product Description
Specifications
1.Using pure cotton or EB canvas as carcass2.Good delasticity, anti-impact, higher strength
3.Good wear ability
Key Features and Benefits:
Good delasticity, anti-impact
High adhesion, good flexing capacity
Good trough ability
Higher strength, smaller thickness and weight compared with EB belts
Good resistance to moisture and heat, corrosion resistant
Good wear ability and long service life
Technical list:
Cover rubber properties
Index | type of cover and performance | ||
H | D | L | |
Tensile strength Mpa ≥ | 24.0 | 18.0 | 15.0 |
Elongation at breaking % ≥ | 450 | 400 | 350 |
70*168h tensile strength after aging changing rate of elongation at breaking | ±25 | ±25 | ±25 |
abrasion loss mm3 | 120 | 100 | 200 |
H-cut and gouge resistance D-superior in abrasion resistance L-general purpose | |||
Adhesion-ply to ply
Index | Canvas ply to canvas ply | Cover to belt core | |
cover thickness | |||
0.8-1.5mm | 1.5mm | ||
average value of samples N/mm≥ | 3.2 | 2.1 | 2.7 |
bottom value of samples | 2.7 | 1.6 | 2.2 |
remark: The bottom value of sample can not surpass 20N/mm | |||
Performance of belt:
Elongation of fixed burden:≤4%
Extensibility at breaking:≥10%
Applications:
Suitable for conveying systems in the industries of metallurgy , mining, power, construction materials etc. and for middle and short distance conveying of non-corrosive materials in shape of mass, granule and power under normal temperature.
