Self bonding electrical tape
- 4000 Piece / Pieces per Month
- Qingdao
- T/T Credit Card
You May Like
-
Rubber High Tensile Kraft Flatback Carton Sealing Tape with Paper Backing
-
rubber insulation tape rubber tape rubber sealing tape
-
rubber wrap tape rubber insulation tape rubber sealing tape
-
Wonder butyl self fusing silicone tape
-
High-Voltage Self-Fusing Rubber Tape - Electrical Insulation Tape
-
rubber selfadhesive mastic tape rubber insulation tape rubber tape
Product Details
Material | Other, PVC, rubber, SBR | Use | Masking | |
Adhesive Side | Single Sided | Adhesive | Rubber | |
Adhesive Type | Pressure Sensitive | |||
Design Printing | Offer Printing | Place of Origin | Shandong, China | |
Brand Name | Haijia | Model Number | 7217 |
Product Description
Self bonding electrical tape
It is an ethylene propylene rubber based high voltage tape possessing superior electrical, chemical, mechanical, and thermal properties. It is a self bonding tape that fuses quickly yielding a void-free, electrically stable build-up. It is also compatible to all extruded dielectric cable insulation.
PROPERTY VALUE UNIT TEST METHOD
Total thickness 0.8 mm ASTM-D-4325
Tensile strength 250 Psi ASTM-D-4325
Elongation at break 700 % ASTM-D-4325
Continuous operating
temperature 90 °C ASTM-D-4325
Emergency overload
temperature 130 °C ASTM-D-4325
Water absorption 0.02 % ASTM-D-570
Ozone resistance pass - ASTM-D-4325
UV resistance pass - ASTM-D-4325
Electrical property
Dielectric strength 600 V/mil ASTM-D-4325
Dielectric Constant
24h@23 °C 2.6 -- ASTM-D-4325
168@70 °C 2.6 -- ASTM-D-4325
Dissipation Factor
24h@23 °C 0.001 -- ASTM-D-4325
168@70 °C 0.005 -- ASTM-D-4325
Volume Resistance 10 16 ohm-cm ASTM-D-4325
Recommended Use
For insulating and jacketing of splices on power cable from 600volts through 138,000volts and forbuilding stress cones and jacketing of terminations on power cable from 600volts through 35,000volts. A major component in transition joint construction.
Why do you choose us?
1. 10 Years' experience for tapes.
2. Leading manufacturer with ISO 9001:2008 & SGS certifications.
3 Good prestige and strict quality management.
4.Pefect after-sale service.
Qingdao Haijia Revertex Co.,LTD is an integrated factory specialized in R&D, manufacture and
sales of adhesive tapes.Founded in 2005 and located in costal city of Qingdao.
We are a key supplier to influencial companies in home appliance,electronics and automobile industries both home and abroad.
We have won good market in Japan, EU, south Asia and south America.Adhering to the principle "striving for survival by quality,seeking for development by credibility".
- Your inquiry related to our product & price will be replied within 24 hours. Well-trained & experienced staffs are to answer all your inquiries in English of course.
- OEM&ODM projects are highly welcomed. We have strong R&D team here to help. Your business relationship with us will be confidential to any third party.
- Good after-sale service offered, please get back if you got question.
Suggestion for inquiry
- If you have a sample in hand, and want to buy the same goods for it, please send you inquiry with the real picture, sizes, packing requirements, qty, etc.
- If you are purchasing this item, please send us full details including the thickness, length, width, packing, application of the tape, and the quantity you need.
