Home > Manufacturing & Processing Machinery > Plastic Machinery > Plastic Extruder > PE Drip Irrigation Tape Mould Dia477.5mm
PE Drip Irrigation Tape Mould Dia477.5mm
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, Belt
Plastic Processed:
PE
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo seaport
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PE Drip Irrigation Tape Mould Dia382mmUS$ 3,000 - 5,000MOQ: 1 Set -
Drip Irrigation Tape Production LineUS$ 29,500 - 35,000MOQ: 1 Set
-
PE Drip Tape Mould ( Irrigation Drip Tape Prodcution Line)NegotiableMOQ: 1 Set
-
Drip Irrigation Tape MouldUS$ 5,000 - 8,000MOQ: 1 Set
-
Labyrinth Drip Irrigation Belt Production Line( Dia50,55,65mm Single Screw and Barrel)US$ 15,000 - 25,000MOQ: 1 Set
Condition
New
Application
Other, Belt
Plastic Processed
PE
Screw Design
Single-screw
Place of Origin
Zhejiang, China
Brand Name
PUTUOSHAN
Model Number
Mould Dia382mm
Specifications
The line uses PE material to produce labyrinth water conveying tape, it is widely used in water saving
The line uses PE material to produce labyrinth
water conveying tape, it is widely used in water
saving and irrigation of agriculture field (cotton,
grapery and wheat etc), also can be used
in desert, wilderness, mountain and hilly land.
It can be lay in a long distance and pressure
changing area.
φ477.5mm
Outside diameter of mould: φ477.5mm
Mounting height: ≥250mm
Output: 55-65m/min
Double moments winder: using torque motor
Length of single winding: 500-2000m
Inside diameter of drip tape: φ12-φ20mm
Wall thickness of drip tape: 0.16-0.24mm
Hole space: 250mm, 300mm, 500mm, 750mm
Flux of water dropper: 1.2-4.0 L/H
Warp of flux: ±5%
Operating pressure: 0.1-0.18Mpa
