2015 best sales rubber powder cryogenic pulverizer

1. What material you want to grind, is it dry, what is the size of feed material ?

2. What capacity you expect ? (kg/h)

3. What mesh or mm or micron(size) of the powder you want?

4. What voltage you want? For example, 380V 50hz 3p; 440V 60Hz,3p; 220V...etc.

      (We only provide 3P, because our machines are all for industrial use,not for family.)

5. Usually we use stainless steel 304, if you want stainless steel 316, it's OK and please tell us.

Working Principle:

Freezed by the nitrogen, the material becomes brittle and is fed into the grinding chamber, in which, the material is impacted, sheared by the blade, hammer into fine powder. The final powder comes out from the cyclone. The size of the powder is controlled by the classifying device. Most of the cold air goes back to the feed hopper to freeze the material.

Characteristic:

During the work, it is the close circulating system for the cold air, which ensures to make the best of the nitrogen energy sources. The lowest temperature is minus 196 Degree C. According to the brittle point of different material, the temperature can be changed to the best status. The final size of the powder can be 10-1000mesh. The application of the liquid nitrogen also avoids the exposition and oxygenation-proof.

Technical Parameters:

*diameter of the grinding chamber: φ450mm

*gross power: 57KW

*working medium: liquid nitrogen

* working temperature: 0~-196DC

*fineness: 10-1000mesh

 A. Technical service

1, We calculate the capacity and recommend the best models.
2, We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.
3, We supply the spare parts and technical support in & after the warranty time.
4, We supply the training course to your workers at our factory if you need.

B. After-sales service
1, Technical support for your installation, operation and maintenance.
2, One year’s warranty, and you can pay for extended warranty.
3, Spare parts and technical support at most economic prices after the warranty.
