Hydraulic EPDM paver machine
Manufactured by the Company TPJ-2.5-type paver machine, is a technology with higher
levels of plastic track laying machine, which employs advanced technology and Siemens frequency
stepless speed regulation of hydraulic gear to increase their degree of automation built performanceof the construction of venues able to satisfy the requirements of the quality of the playing field to achieve target, with high efficiency, low consumption, high-quality and easy operation, with long-term use of authentication, by the majority of users at home and abroad,and by the People's Republic of China National Sports Center for Quality Supervision,Inspection and Recognition, awarded a certificate.
Technical Data:
Paving Width |
2500mm |
Moving Speed |
0.8-6m/min |
Paving Capability |
500m2/h |
Power |
8kw |
Adjusted data of hydraulic pressure system |
8Mpa |
Adjusted temperature for electric board |
90oC |
Machine Weight |
900kg |
Appearance measurement |
3000×1800×720mm |
A. Technical service
1, We calculate the capacity and recommend the best models.
2, We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.
3, We supply the spare parts and technical support in & after the warranty time.
4, We supply the training course to your workers at our factory if you need.
B. After-sales service
1, Technical support for your installation, operation and maintenance.
2, One year’s warranty, and you can pay for extended warranty.
3, Spare parts and technical support at most economic prices after the warranty.
