1000w Solar Panel Kits

Solar power station specifications

AC220V two phase output complementary type polycrystalline silicon solar energy power supply system

Notes

Load power for 1800W/AC220V, at the same time the rate of utilization rate 70%

Solar electric power supply time every day  hour)

4

Load

Sunny daily capacity of the estimated       (W.Hr)

16800

Namely is 16.8degrees electricity

The biggest consumption power of load every day  (W.Hr)

12600

Namely is12.6 degress electricity

when overcast or rainy day solar electrical energy generation will shortage

The power system supply to store more than 12-24HOURS

Solar panel array

Choose solar panels veneer peak power            (Wp)(work power)

200

36V/5.55A

A dopt the number of solar panels                         (piece)

5

The total output of peak power array panels         (Wp)

1000

Single piece of panels shape dimension              (mm)

L:1646*W:995*T:50

Single plate weight 19.13kg

The array panels covering a total area                     (M²)

11

Panels assign planar graph

Each Watte prices of panels

Total price of panels

Battery

The selection of high quality whole sealing,Free maintenance lead-acid battery specification

DC12V

Battery number      (piece)

4

Lifetime:3-5years

Total capacity battery pack(Ah)

24V/500AH

Work temperature: -50~+70°C

The total price of battery

Other configuration

Automatic switching charging discharge 1 set of controller

Specification:DC24V/100A

Three-phase sine-wave inversion

 DC24V/AC220V 1000W

Ac output power distribution ark

Other costs

Panels array stents, battery rack

Solar power generating system,complementary materail
