Small Diesel Water Pump

Specifications

Small Diesel Water Pump

• Diesel water pump,garden pump,pump,
• Powered by air-cooled, 4-stroke diesel engine
• Large volume water discharge
• Highly effective mechanical seal
• Compact and light weight structure
• One year warranty
• high quality
• Aluminum alloy high pressure casting
• Full frame protection offers exceptional performance even in the toughest conditions
• Large fuel tank ensures hours of continuous running
• Pump head as same as HONDA pumps
• 5% easy broken spare parts will be provided to the buyer for free for container order

Specifications:

• PUMP Model	DWP50	DWP80	DWP100
  Suction port dia. (mm)	50 (2 in)	80 (3 in)	100 (4 in)
  Max. Capacity [m3/hr]	36	60	96
  Max. Head (m)	26	25	31
  Self-priming time(s/4m)	80	120	180
  Max. Sucition Head (m)	8	8	8
  Engine Model	JD170	JD178	JD186
  Engine type	Single-cylinder, 4-stroke, air-cooled diesel engine
  Cont. Output(hp)/(rpm)	4.0	6.0	11.0
  Displacement (cc)	219	306	418
  Fuel tank capacity (L)	3.5	3.5	3.5
  Net weight (kg)	42	50	70
  Dimensions (LxWxH)	510*425*555	560*490*595	660*510*635
  20ft Container QTY	236	132	114
  40HQ Container QTY	492	384	320

 Accessories for each water pumps:

• 	Engine tool kit (1set)
  Standard Accessories	Starter (1pc)
  free	Hose coupling (2pcs)
  	Hose band (3pcs)

DWP50 :

 DWP80:

DWP100:
