diesel generator diesel generator set diesel silent generator 390kw Water Cooled Silent Genset from website id emily58583

Specifications

100kw Water Cooled Silent Generator
ISO,CE, Soncap,POVC,CIQ
Safe running
Low fuel consumption

















100kw Water Cooled Silent Generator









Genset:
1)Power range: 7kw-1000kw
2)110V-480V,50HZ/60HZ
3)phase,4wire,12leads
4)Single/three phase
5)water cooled/air cooled
6)Silent/weather proof/trailer type
7)Fuel tank for at least 8H running
8)Two 12V batteries
9)24V charge alternator
10)50 degree C Radiator

Engine:
1)Engine:Deutz,Volvo,Dawoo,MTU and Chinese famous

water-cooled diesel engines
2)50HZ or 60HZ
3)2,3,4,6,12 cylinders
4)low fuel consumption
5)Rated power factor:0.8(lagging)
6)102/120,114/135,140/152,159/159mm bore/stroke
7)standard starting method:24V electric starting
8)cooling method: closed water-cooled
9)lubricating methond:colsed lubricating
10)stable governing rate=5%
11)minimum oil consumptiong:=1.36g/kw.h
12)minimum fuel consumption:=205g/kw.h

Alternator:
1)Alternator:Stamford/OEM Stamford/other blands brushless alternator
2)CLASS H insulation
3)IP21 protection
4)self-regulator by AVR
5)50hz /1500rpm or 60hz/1800rpm
6)110-480V,3 phase,4wire,pf.0.8
7)electric system:24V/12V
8)wave distort:less then 10%

Soundproof/Silent box:
1)Excellent ventilation
2)Fuel tank mounted on baseframe for 12 Hours working
3)Highly Corrosion Resistant construction
4)Excellent Access for Maintenance
5)Security and Safety
6)1m<80DBA / 7m<70DBA
7)Many colours for choice

Control panel:
1)Automatic control panel(AMF),LED display.
2)Four protection systems
3)Emergency stop
4)DSE/COMAP/SMARTGEN/HARSON series controller









Optional:
1)Trailer type
2)Soundproof / water proof
3)ATS(automatic transfer switch)
4)water Heater
5)Parallel system
6)Remote system
