Rmini small River Sea Sand Hydraulic Cutter Suction Dredger in China

Rmini small River  Sea Sand Hydraulic Cutter Suction Dredger in China photo-1
Rmini small River  Sea Sand Hydraulic Cutter Suction Dredger in China photo-2
Rmini small River  Sea Sand Hydraulic Cutter Suction Dredger in China photo-3
Rmini small River  Sea Sand Hydraulic Cutter Suction Dredger in China photo-4
Rmini small River  Sea Sand Hydraulic Cutter Suction Dredger in China photo-5
Rmini small River  Sea Sand Hydraulic Cutter Suction Dredger in China photo-6
US$ 600,000 - 700,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Cutter Suction Dredger
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Cutter Suction Dredger
Power Type Diesel
Dredging Depth 14 m
Draught 110 cm
Place of Origin Shandong, China
Brand Name Yongsheng
Model Number CSD-300
Dimension(L*W*H) Customized
Weight customized
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Overseas service center available

  River Sea Sand Hydraulic Cutter Suction Dredger in China



Introduction for Yongsheng Dredging Machinery



rmini small river  sea sand hydraulic cutter suction dredger in China

rmini small river  sea sand hydraulic cutter suction dredger in China



Our company is the leading manufacturer of dredger in China, we are into this business for 20 years and now we have up to 130,000 M3 workshop and more than 100 engineers and skillfull staff ,we also obtained advanced technology from Germany,America, Holland. we gained ISO9001 Internationl Quality System Certificate , Ship Inspection Certificate of ZC & CCS, besides, we also have Europe CE Certificate , our dredgers have been sold to abroad such as Poland ,Russia, Venezuela,India,Qatar, Lybia ,Nigeria,Iran, Saudi Arabia,Korea and so on , more than 33 countries.



The CSD300-2 Dredger Specification

rmini small river  sea sand hydraulic cutter suction dredger in China





1. GENERAL SPECIFICATION

No.

Item

Parameters

Total Length

(with ladder raised)

35 m

2

Hull Length

25.0 m

3

Hull Width

6.6 m

4

Hull Depth

1.8 m

5

Mean Draft

1.30 m

6

Dredging Depth

14.0 m

7

Discharge Distance

1500 m

8

Dredge Pump Water flow

2000m3/h



2. Marine Diesel Engine (2)

Item

Main Engine

Generator

Standby Generator Set

Manufacturers

WEICHAI

SHANGHAI

WEICHAI

Model

8170ZC

SHQH24

4100

Power

601kw

24kw

24kw

Amount

1 Set

1 Set

1 Set



Item

Main Engine

Generator



Manufacturers

WEICHAI

   Marathon



Model

6160ZC





Power

220kw

24kw / 32HP



Amount

1 Set

1 Set







3. Dredging Pump (1)

Item

Parameters

Note

Made

Warman Technology, Australia

SHIJIAZHUANG  PUMP GROUP

Type

300G-GH

Dredging Pump

Capacity

2000m3 per hour



Head

40-62 m



Speed

400—550 r/min



Efficiency

74—78%



NpSHr

little than 4 m



Pump Suction Diameter

350 mm



Pump discharge Diameter

300 mm



Max.Diameter of Flowed Partice

226 mm



    rmini small river  sea sand hydraulic cutter suction dredger in China



rmini small river  sea sand hydraulic cutter suction dredger in Chinarmini small river  sea sand hydraulic cutter suction dredger in China

We use excellent product quality and after-sales service to win customers and establish a stable market. Our products sell to more than 30 provinces, municipalities, and autonomous regions, and are successfully exported to North Korea, Russia, South Korea, South Africa, Nigeria, and other countries and regions. We received a wide acclaim and established long-term cooperation relationships with domestic and overseas customers.

"Take quality to survive, credibility to develop" is our company's business objective. "High starting point, high standard, high quality and high benefit" is the work principle of our company. We provide service to community and open up markets to create brilliance together with the vast number of merchants.

Company tenet-Agglomerating scientific and technological force and continuously taking the respective cause into common cause

Enterprise spirit-relying on market, pioneering spirit, quality and credibility is always the first.

Management principle-perfect quality system, implementing quality principles, and achieving quality objectives ensure customer satisfaction.

Struggling goal-To become China's largest professional manufacturing company of sand mining machinery, dredging machinery, mineral machinery.

On the basis of many years' exporting experiences, we have opened a new export company, Qingzhou Wealth Import & Export Co., Ltd. And our main business is the exporting of loader, concrete mixing plant, dredger, water treatment equipment, packing machinery and other machinery
