Specifications
2000cbm/h hydraulic cutter suction dredge1. Total length: 35m
2. Dredging depth: 16m
3. Pump water flow: 2000cbm/h
The CSD300-2 Dredger Specification
==================================================================================================
1. GENERAL SPECIFICATION
No. | Item | Parameters |
1 | Total Length (with ladder raised) | 35 m |
2 | Hull Length | 25.0 m |
3 | Hull Width | 6.6 m |
4 | Hull Depth | 1.8 m |
5 | Mean Draft | 1.30 m |
6 | Dredging Depth | 14.0 m |
7 | Discharge Distance | 1500 m |
8 | Dredge Pump Water flow | 2000m3/h |
2. Marine Diesel Engine (2)
Item | Main Engine | Generator | Standby Generator Set |
Manufacturers | WEICHAI | SHANGHAI | WEICHAI |
Model | 8170ZC | SHQH24 | 4100 |
Power | 601kw | 24kw | 24kw |
Amount | 1 Set | 1 Set | 1 Set |
Item | Main Engine | Generator |
|
Manufacturers | WEICHAI | Marathon |
|
Model | 6160ZC |
|
|
Power | 220kw | 24kw / 32HP |
|
Amount | 1 Set | 1 Set |
|
3. Dredging Pump (1)
Item | Parameters | Note |
Made | Warman Technology, Australia | SHIJIAZHUANG PUMP GROUP |
Type | 300G-GH | Dredging Pump |
Capacity | 2000m3 per hour |
|
Head | 40-62 m |
|
Speed | 400—550 r/min |
|
Efficiency | 74—78% |
|
NpSHr | little than 4 m |
|
Pump Suction Diameter | 350 mm |
|
Pump discharge Diameter | 300 mm |
|
Max.Diameter of Flowed Partice | 226 mm |
|
