CUTTER SUCTION DREDGER

Name: CUTTER SUCTION DREDGER
Brand: YONGSHENG DREDGER
SKU: 143489658
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Cutter Suction Dredger

Place of Origin:

Shandong, China

Qingzhou Yongsheng Dredging Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

TIANJIN

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Cutter Suction Dredger

Place of Origin Shandong, China

Brand Name YONGSHENG DREDGER

Model Number CSD-300

Specifications

1.Quick delivery
2.Full technic support
3.Full after service
4.Successful project cases

Cutter Suction Dredger
Model: YS-CSD300
Item	Specification	Remark
Total Length	35m	Ladder raised
Hull Length	25.2m
Hull depth	1.80m
Hull width	6.00m
Mean draft	1.20m
Dredging Depth	15.0m
Internal diameter of suction pipe	Φ400mm
Internal diameter of discharge pipe	Φ400mm
Discharge Distance	1500m
Main Engine	Power: 820kw/1100HP	Power Pump
	WEICHAI Diesel Engine
	Type: 8200ZLC
Standby Diesel Engine Generator Set	24kw/32HP	WEICHAI POWER
Dredging Pump	Model : 300G-G	SHIJIA ZHUANG PUMP Warman technic of Australia
	Water flow: 2000m³/hr
	Total head: 65m
Hydraulic coupling	Model: YOTZJ650 CNPC JICHAI	Variable –Speed Hydraulic coupling Transmission
Hydraulic Winch	Cutter ladder winch: 60KN	1set
Hydraulic Winch	Swing winch: 60KN	2sets
Cutter	Cutter Diameter: 1500mm
	Power: 120kw/162HP
	Speed: 0-30rpm
Spud hoisting hydraulic cylinder	Travel: 2.50m	2 pieces
	Cylinder diameter: 160mm
	Working pressure: 16Mpa
Spud	Spud Outside Diameter: Φ450mm	2 pieces
Spud	Spud Length: 18m/piece	2 pieces
Deck Crane	Lifting power: 3.0 Tons	1 piece
Hall anchor for swing wires	500 kg / piece	2 pieces
Total max weight when working	160T
Operation System	PLC Hydraulic Operation System
Operating Cabin	With air condition, All the operating system with English description. A small chart table and a low sofa for two persons to sit.
Room below operating cabin	To provide toilet and shower facility.
Steel wire rope	Have safe package on each joint
Spray-paint	3 layers, Anti rust.
Zinc Anode	8 x 1.5kg Zinc Anode on dredger’s hull with one year protection guarantee.
