Help CenterDredging Machine
Related Products
Specifications
1.Most advanced PLC control system2.Good structure
3.Strong adaptability
4.Good after-sell service
5.Quick delivery
Features:
1.Simple, rapid assembly and dismantling.
2.Spare parts and floating pipe available.
3.Transportable by road, rail or sea.
4.Reliable hydraulic system.
5.Fresh water engine cooling system.
6.Efficient fuel consumption.
7.One-man operation.
8.The most advanced PLC control system.
Cutter/Suction Dredger,Type:YS-250 | ||
Items |
Specs |
Remarks |
Total Length |
25.m |
|
Body Length |
18.0m |
|
Hull depth |
1.6m |
|
Hull width |
5.2m Side Pontoon 1.5m, engine room: 2.2m |
|
Main Power |
450KW JICHAI Diesel G-6190ZlC-3, |
Pump Power |
Auxiliary Power |
24KW |
|
Pump model |
WN250 Suction12" Discharge10" Maxium power: 300KW |
Shijiazhuang |
Pump Suction Dia |
300mm |
|
Pump Discharge Dia |
250mm |
|
Water flow |
1200m³/h |
|
Discharge Distance |
1000m (Maximum ) |
|
Total max weight when working |
80T |
|
Spuds |
Dia : 377mm Two sets (Hydraulic cylinder control) |
13 metre |
Winches |
3 Sets Hydraulic Winch Ladder winch: 40KN, Side winch: 40KN ×2 |
|
Operation System |
PLC Hydraulic System |
|
Operating Cabin |
With air condition. All the operating system with English description. |
|
Dredging depth |
1-10m |
|
Dredger Steel |
Bottom: 8mm, Side wall: 6m, Deck: 6mm |
|
Send Inquiry to This Supplier
