The CSD350 Dredger - Technical Speification
==================================================================================================
1. GENERAL
No. |
Item |
Specification |
1 |
Total Length (with ladder raised) approx |
35m |
2 |
Length over pontoons |
25.00m |
3 |
Breadth |
7.2m |
4 |
Depth |
1.90m |
5 |
Main pontoon |
18.00m × 3.50m × 1.90m |
6 |
Side pontoon |
25.00m × 1.850m × 1.90m |
7 |
Mean draught with full bunkers approx |
1.3m |
8 |
Maximum standard dredging depth |
15.00m |
9 |
Dredge pump water flow capacity |
3000m3/h |
10 |
Standard discharge distance |
1500m |
11 |
Cut Width @ Maximum digging depth |
35m |
12 |
Cut Width @ Minimum digging depth |
44m |
2. Marine Diesel Engine to drive dredger pump
Item |
Main Diesel Engine |
Manufacturers |
JICHAI ENGINE |
Model |
8190ZLCZ-R |
Continuous Power |
720kw@1450rpm |
Amount |
1 Set |
Marine Diesel Engine to drive hydraulic system
Item |
Main Diesel Engine |
Manufacturers |
WEICHAI |
Model |
ZCW-6160 |
Continuous Power |
270kw@1000pm |
Amount |
1 Set |
3. Dredge Pump
Item |
Parameters |
Note |
Made |
Warman Technology, Australia |
SHIJIAZHUANG PUMP GROUP |
Type |
350G-H |
Professional Dredge Pump |
Capacity |
3000m3/h |
|
Head |
65 m |
|
Speed |
400—550 r/min |
|
Efficiency |
74—78% |
|
NpSHr |
small than 4.5 m |
|
Pump Suction Diameter |
400 mm |
|
Pump discharge Diameter |
350 mm |
|
Max.Diameter of Flowed Partice |
201 mm |
|
Solid Capacity |
450m3/h |
Count 15% solid |
- Our principles and services
1. Yongsheng company sings a long-time after-sale service agreement with customers.
2. We provide rational and practical design according to customers' request.
3. We send engineers to assemble and test the machine within the period as agreed in the contract.
4. Within warranty period, we provide free repair if quality problems emerge.
5. We provide free training of operation and maintenance for customers.
6.We supply high quality accessories in low price.
7. We make an excellent filing of customers for long-term following-up service.
Any interest in our products, pls kindly contact us without any hesitation!
