gold dredge for sale with gold chuting system
- 25 Set / Sets per Month
- Tianjin Port
- Gold mining jaw crusher equipment for sale, stone crusher machine
- First-rate high efficiency SZZ series self-centering vibrating screen with ISO 9001 Certificate
- China leader manufacturer ZHAOXIN high efficiency thickener
- Ore benefication thickener machine, dewatering thickener price
- china high quality center drive thickener, thickening equipment
- Shandong Province high efficiency center drive thickener NZ-12, thickening machine
Product Details
Place of Origin: | Shandong, China | Brand Name: | YS Dredger | Model Number: | gold machine |
Condition: | New |
Product Description
Dredging Depth-16m,100m³/h | ||
Item | Parameter | Material |
Dredging Bucket | 94 pcs |
|
Hull(L×W×H ) | 31mX2mX1.14m | Hull plate4mm,Deck-3mm anti-skidding steel plate. Keel-- 6#angle steel, 10# U-steel support per layer. |
Frame(L×W×H ) | 6.5mX1.25mX1.25m | 16#square steel and 16#U steel |
Ladder | 2152cmX110cmX85cm | Bottom- 14# square steel Top- 14# U-steel |
Pentagon Wheel | Dia-130cm Width-80cm | Steel Plate- 25mm |
Trommel Screen | Dia-130cm ,Length-160cm | 19#Round steel (Oil drilling lift stem) |
Gravel Chute | Length-6m |
|
Link Plate (consolidation) | 670mmX90mmX28mm | 65# manganese, high frequency |
Bucket | Capacity- 0.06m³/bucket |
|
Gearbox | JZQ850*1set,JZQ500*1set,350*3sets,250*2sets | ZIBO CHUANG YING |
Electric motor | 8y45kw,18kw*1,7.5kw*3sets 4kw*2 sets | SHANDONG HUALI ELECTRIC LTD |
Magnetic Separator | 900mm*2200mm (3500GS) | 4KW, Seperation with water |
Gold Chute | 800mm*4500mm/set | 4.5m*4sets (Prolong according to site condition) |
Water Pump | 100m³/h | 10KW |
Cabin | 1.8m*1.5m | Operation Board /Chair |
Power | 100kw Diesel generator | WEICHAI,brushless generator |
Pins | Length -13cm | Carburization |
Small tugboat | 5000cmx2000cm | 2 pcs |
ASSEMBLE DREDGER
1)Our company will send 2-3 qualified and experienced engineers to install the dredger and train your workers to operate the dredger.Meanwhile,buyer should arrange 6-8 workers to help our workers.
2) The installation period is expected 15-20 days, the buyer should provide cranes or other necessary equipments to install the dredger.
Warranty of dredger
Will provide 12-months warranty for the quality of the diesel engines, generators, gear boxes, dredge pumps, Hydraulic system, PLC control system.
1) 12 months manufacturing warranty on all new installed component parts.
2) 12 months warranty on hull and all fabricated parts.
3) Wearing parts are not included.
( for example: Cutter tooth , suction/discharge pipe)
After-sale service
During the warranty period , We will provide free parts and on-site technical guidance . After the warranty period, We will provide free on-site technical support quickly, if the shipowner need. But if the dredger need replacement parts, the cost paid by the owner.
