iron seperation ship
- 10 Set / Sets per Month
- Qingdao
Product Description
Specifications
1.power:75kw2.digging depth:10m
3.sand capacity:120m3/h
4.recovery rate:85%
5.operated by the electric
Our company is a professional manufacturer of dredgers and some other related products,such as processing gold ship,sand sucking ship,crusher and so on.
1.power:75kw
2.digging depth:10m
3.sand capacity:120m3/h
4.recovery rate:90%
5.operated by the electric
6.It is easy to operate and strong to adapt.
The dredger is mainly used in the river,channel,reservoir which the sand in good condition to dredge and backfill.
Jet Suction Iron Separation Dredger | |||
Item | Parameter | Note | |
Total Length | 20m |
| |
Hull Depth | 1.4m |
| |
Hull Width | 6.0m |
| |
Roll Sieve | L 2.75m,Dia 1.4m |
| |
Drum high intensity permanent magnetic separator | Dia:1050mm,Length2800mm 4 sets | Magnetic density of surface roller-3800GS | |
Pump unit | Sand pump | 12/10’’ | SHIJIAZHUANG PUMP |
Marine gearbox | 120B Speed rate- 2-1 | CHANGZHOU | |
Diesel engine | 163kw | WEICHAI POWER | |
Jet Head Winch | Reducer | 350 |
|
Electrical Motor | 7.5kw |
| |
Move winch | Reducer | 250 |
|
Electrical Motor | 2.2kw |
| |
Roller Siever | Reducer | 500 |
|
Electrical Motor | 15kw |
| |
Iron powder pump
| Slurry pump | 37kw |
|
Electrical Motor | 37kw |
| |
Drum permanent magnetic separator | Magnetic seperator | 1050*2800 | 3800GS |
Electrical Motor | 5.5kw |
| |
Reducer | 350 |
| |
Generator | Three-phase brushless AC- synchronizing generator | 100kw | QIANGHUI.SHANGHAI
|
Diesel engine | 163kw | WEICHAI | |
Jethead pump | Water pump | 35kw Head- 26.7m ,300m³/h | LUYUAN PUMP |
