1.Material : High tensile steel cable mesh
2.Specification :
Opening(mm) |
Wire diameter(metal wire)(mm) |
Wire diameter(PVC coate)/inner/outside*(mm) |
strands |
60*80 |
Ø2.0-2.8 |
Ø2.0/3.0-2.5/3.5 |
3 |
80*100 |
Ø2.0-3.2 |
Ø2.0/3.0-2.8/3.8 |
3 |
80*120 |
Ø2.0-3.2 |
Ø2.0/3.0-2.8/3.8 |
3 |
100*120 |
Ø2.0-3.4 |
Ø2.0/3.0-2.8/3.8 |
3 |
100*150 |
Ø2.0-3.4 |
Ø2.0/3.0-2.8/3.8 |
3 |
120*150 |
Ø2.0-4.0 |
Ø2.0/3.0-3.0/4.0 |
3 |
3.Slope protective wire mesh
The rock fall barriers and fences are composed of high strength wire grid mesh, the anchor, I-steel column, the drop-down anchor rope, the ring of energy dissipation, and the base of support rope from top to bottom, and other components. Rock fall protective fences protect the formation of the regional slope, and prevent the collapse of the rock fall.
Steel rope consisted rock fall barriers defense system is flexible to intercept and strong enough to absorb and spread the rocking, and energy dissipation of the ring net help the system’s ability to further improve the impact resistance.
4.Applications:
1).Flood bank or guiding bank
2).Preventing of rock breaking
3).Water and soil protection
4).Bridge protection
5).Strengthening structure of soil
6).Protection engineering of seaside area
