Specifications
Dutch woven wire cloth,dutch weaving wire mesh,weaving clothPlain ductch woven wire cloth,also named by plain dutch weave wire cloth. It is the most common wire cloth used and it is one of the simplest wire cloths
Weaving type:plain dutch weave,each warp wire and each weft wire passes over and under adjacent complementary wire,as in normal plain weave,except the warp wires are larger in diameter than the weft wires.
Material:stainless steel AISI304,304L,316,316L.
Special steel: Cromax, Incoloy, Alloy Ni-Cr, Inconel, Nichel, Monel, Titanium, Duplex. And low-carbon steel.
Uses:Stainless Steel Dutch Woven Wire Cloth is utilized as filter fittings for
chemical industry, medicine, petroleum, telecom-communication, scientific
research units and so on.
Property: Cloth offers good wear-resistance, heat-resistance, acid-resistance and
corrosion resistance.
Charactristics:”Zero”-aperture,more solid than square or rectangular mesh,relative high open area,suiltable for all kinds of filtration.
| Mesh | Wire diameter | Weight for one sq.(kg) |
| 6x 68 | 0.70 x 0.40 | 3.45 |
| 7 x 68 | 0.60 x 0.40 | 3.35 |
| 8 x 68 | 0.60 x 0.40 | 3.44 |
| 9 x 68 | 0.50 x 0.40 | 3.28 |
| 10 x 83 | 0.50 x 0.35 | 3.17 |
| 11 x 91 | 0.45 x 0.30 | 2.60 |
| 12 x 91 | 0.45 x 0.30 | 2.64 |
| 13 x 101 | 0.45 x 0.28 | 2.63 |
| 14 x 101 | 0.40 x 0.28 | 2.52 |
| 15 x 101 | 0.40 x 0.28 | 2.58 |
| 16 x 125 | 0.35 x 0.22 | 2.01 |
| 17 x 125 | 0.35 x 0.22 | 2.07 |
| 18 x 140 | 0.30 x 0.22 | 2.09 |
| 19 x 140 | 0.30 x 0.20 | 2.11 |
| 20 x 152 | 0.28 x 0.18 | 1.62 |
| 22 x 170 | 0.28 x 0.16 | 1.51 |
| 25 x 170 | 0.25 x 0.16 | 1.48 |
| 30 x 170 | 0.22 x 0.16 | 1.45 |
| 40 x 210 | 0.20 x 0.14 | 1.43 |
| 50 x 210 | 0.20 x 0.12 | 1.25 |
