88 Bend With Door Cast Iron Pipe Fittings

FOB Price

US$ 600 - 1,000 / Ton

1 Ton(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Advantages

1) strength and non-combustible

2) noise reduction

3) enviroment friendly, recyable

4) simple in design and install

5) lighter weight compared with sand-mould casting pipes and its

laying length increases 20-30% consequently.

Product List

Products list
1	M&F Long Sweep Bend			290	Beaded Plug
2	Long Sweep Bend			291	Plain Plug
85	Crossovers			301	Round Cap
90	Elbow			310	Backnut
92	M&F Elbow			330	Union,Flat Seat
95	Union Elbow Flat Seat			331	M&F Union ,Flat Seat
97	M&F Union Elbow Flat Seat			340	Union,Taper Seat
120	45° Elbow			529	M&F Socket
130	Tee			90R	Elbow Reducing
180	Crosshead Female			130R	Tee Reducing
270	Entire Threads Socket			240	Socekt Reducing
270	Part Threads socket			241	Bushing
280	Hexagon Nipple			245	Nipple Reducing
Size		3/8”-6”		Material	Malleable Iron
Finishing		(Black) Painting, Galvanizing, Elctro-plating
Type		Banded, Beaded , Plain
Standard		ISO5922/IS049/ISO7-1 , BS EN1562:1997, DIN 2950/1692/2999
Mechanical Properties		Tensile Strength≥330MPA, Elongation rate≥8%, Hardness≤HB150
Mechanical Properties		C:2.4~2.9 Si:1.2~1.7 Mn:0.3~0.55P:0.12 S:0.18 Cr:0.09
Working pressure		Max 1.6MPA	Working temperature			Max 200°C
Producing Process		Pattern making - sand casting - heat treatment – galvanizing - threading - air pressure testing - packing
Usage		Fro pipeline convey water ,oil ,gas and so on
Testing		100% Air pressure testing
