MJ-SK380 CE Computer Panel Saw

MJ-SK380 CE Computer Panel Saw thumbnail-1
MJ-SK380 CE Computer Panel Saw photo-1
US$ 1 - 1 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Other
Use:
Woodworking
Contact Supplier Request Quote Chat Now
Longkou Leader Imp& Exp Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other
Use Woodworking
Style Horizontal
Place of Origin Shandong, China
Brand Name LEADER
Model Number MJ-SK380
Voltage 380v
Power(W) 11000 w
Dimension(L*W*H) 6500*7000*2000mm
Weight 5000kg
Certification CE
Warranty 1year
After-sales Service Provided Engineers available to service machinery overseas

computer panel saw

Model: MJ-SK380



 MJ-SK380 CE computer panel saw

Product Description



model

MJ-SK260

MJ-SK320

MJ-SK380
total weight 4200kg 4500kg 5000kg
workbench size 2600mm 3200mm 3800mm
machine length 5300*5500mm 5900*6400mm 6500*7000mm
working pressure 6kg/cm2 6kg/cm2 6kg/cm2
power supply 380v(three phase four line) 380v(three phase four wire) 380v(three phase four wire)
main motor power 7.5kw 7.5kw 7.5kw
feed dirve power 1.5kw 1.5kw 1.5kw
feeding power 1kw 1.5kw 2kw
saw blade projection height ≤75mm ≤75mm ≤75mm
cutting length 2440mm 3050mm 3660mm
cutting speed 0-50m/min 0-50m/min 0-50m/min
cutting straightness precision 0.2mm/2.4m 0.2mm/2.4m 0.2mm/2.4m
feeding precision ±0.3mm ±0.3mm ±0.3mm
catercomer precision 1200/2400<0.7mm 1200/2400<0.7mm 1200/2400<0.7mm
feeding speed 25-30m/min 25-30m/min 25-30m/min
feeding length 2440mm                     3050mm                        3670mm
pneumatic unit Taiwan Actac
electrical components

Touch screen,servo motors,servo drives,frequency converter

,PLC,and text display is reached by Taiwan Taida brand

;Switch and AC contactor:from France, stroke switch:Japan.Motor made in China.
feeding and returning convey mode

chain drive
speed adjust

transducer
feeding rack pneumatic floating beads
positioning mode pulse servo position control
main saw specifications outter dia350mm   inner bore30mm   thickness4.4mm
scoring saw specifications outter dia180mm   inner bore30mm   thickness4.3-5.3mm
main saw rotation 5000rpm
slot saw speed 7000rpm
Company Information

 We are the professional manufacture of woodworking machine since 1991 years, now we become one of the most famous manufacture and exporter in China.

Our Services



If you want to test the performance of machine ,we can sent sample to you with cost offer .



Customized Service :



Our factory has been specialized in producing woodworking machines for over 33 years .We have very high research and development capabilities to meet the requirements of custom.



After-sale Service



1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.

4)Engineers available to service machiner overseas





Packaging & Shipping

 MJ-SK380 CE computer panel saw
