multifunction woodworking machine C400-7

multifunction woodworking machine /multi-use woodworking machine/ combination woodworking machine/combine woodworking machine/planer thicknesser/ wood planer /wood surface planer/surface wood planer/ wood thicknesser/wood thicknessing machine/circular saw/ panel saw/ mortiser machine

model: C400-7

Technical Data:

Features:

1.Panel saw sliding beam

2.Scoring for veneered boards

3.Accurate cross cut fence with flipstops

4.Cast iron construction

5.Sturdy swinging arm squaring frame

6.Inward parallel swing planer table

7.Micro adjust spindle moulder fence

8.3 x 3.0kw class 1 motors.

9. Fully adjustable settings

Product photos:

The C400-7 multifunction woodworking machine has been specifically designed be an industrial standard machine, but at a size intended for the factory and small professional workshop. This industrially rated machine features a table saw and sliding table, planer, thicknesser and spindle moulder unit. The cast iron construction, accurate cross cut fence and superb build quality put this machine in a class of its own.

Being a professional standard machine, the C400 of course is fully adjustable and the accuracy is second to none. As far as accuracy goes it will not even be bettered by full sized industrial machines. With three independent class 1 motors providing ample power, changing function can be done with the flick of a switch rather than the going through the laborious task of changing belts.

The saw utilises a sliding beam which runs along side the blade like a panel saw. By running the beam this close to the blade, 100% accuracy is assured.

The planer thicknessing function, again is of the highest quality, extremely powerful, accurate and the end result is simply sublime. The inward swing of the thicknessing unit keeps this machine compact in every function,whilst the cast iron construction means even heavy pieces can be handled confidently.

Several further options are also available, each machine can therefore be tailored to the users specific needs. These options include; heavy duty morticing unit, spindle moulder ring fence, power feeder and tenoning hood.
