Feature
1. Green and Environmental Protection.
2. It's an efficiently economy energy gasoline pump.
3. Portable and endurable.
4. Low malfunction and reliable &stable performance.
5. Easily maintained.
6.We have satisfactory pre-sale,in-sale and after-sale service.Our after-sales service staff will reply your E-mail within 12 hours.
Product Parameters
| Type | WP10A | WP10B | WP10C | WP10D | WP15A |
| Outlet Size(mm) | 25(1 inch) | 25(1 inch) | 25(1 inch) | 25 (1 inch) | 40 (1.5 inch) |
| Inlet size(mm) | 25(1 inch) | 25(1 inch) | 25(1 inch) | 25 (1 inch) | 40 (1.5 inch) |
| Speed (rpm) | 6500 | 6500 | 6500 | 3600 | 3600 |
| Displacement Q.max(m3/h) | 8 | 8 | 8 | 8 | 12 |
| Lift H.max(m) | 22 | 22 | 22 | 20 | 25 |
| Suction(m) | 7 | 7 | 7 | 7 | 7 |
| Engine Model | 1E40F-5 | 1E40F-5 | 139F | 152F | 154FA/P |
| Engine Type | Air-cooled,single cylinder,2 stroke | Air-cooled,single cylinder,4 stroke | |||
| Bore x Stroke(mm) | 40x34 | 40x34 | 39x30 | 52 x 46 | 54 x 46 |
| Displacement(cm3) | 43 | 43 | 35.8 | 98 | 105 |
| Compression Ratio | 7.7:1 | 7.7:1 | 8.0:1 | 5.5:1 | 6.0:1 |
| Max Power Output(HP/rmp) | 1.5/6500 | 1.5/6500 | 1.3/6500 | 2.5/3600 | 3/3600 |
| Max Torque(Nm/rpm) | 1.8/5000 | 1.8/5000 | * | 3.2/2600 | 3.8/2600 |
| Start Model | Recoil and hand -operated | ||||
| Air Cleaner | semi-dry | ||||
| Fuel Tank Capacity (L) | 1.2 | 1.2 | 0.7 | 1.3 | 1.3 |
| Fuel Consumption(g/Kw.h) | ≤610 | ≤610 | * | ≤450 | ≤450 |
| Oil Capacity(L) | / | / | 0.1 | 0.3 | 0.4 |
| Packing Dimensions (mm) | 390*300*340 | 390*300*340 | 390*300*340 | 360*300*385 | 360*300*385 |
| G.W/N.W(Kg) | 9/8 | 9/8 | 9/8 | 11/10 | 12/11 |
About Us
Taizhou Newland Machinery Co., Ltd here, exports gasoline generator, diesel generator, pumps, engines, gasoline high pressure washer,air compressor, etc, based on over ten years's export experience. Fast-delivery time (15-20days for new customers, 7-10days for old customers) and the monthly output ( over 30000 units ) ensure Newland to become best choice for all customers.
1.Q:Are you a factory or trading company?
A: We are a trading company based on a factory with more than 10 years
processing experience.
2.Q:Where is your factory located?
A: Our factory is in Taizhou city, Zhejiang Province, China.30mins from
Luqiao Airport by car, 2hours from Ningbo Airport by car, 4hours from
Shanghai Airport by car.
3.Q:What is the material of your products?
A: The crank case is made of high quality aluminum with high strength.
4.Q:How about quality control in your factory?
A: Newland people are always paying great attentions to quality controlling from the
beginning to the end.
5.Q:How about guarantee?
A: It's within 1year after goods is discharged in the destination.
6.Q:Can we use our own brand on it?
A: Of course,yes.Our factory has more than 10 years processing experience.
7.Q:How about your MOQ?
A: 50sets.
Taizhou Newland Machinery Co.,Ltd
Jodie Bao
Tel:0086-15757557467
Whats App:0086-15757557467
Skype:newlandmachinery
Address:Shifu Road Jiaojiang District Taizhou Zhengjiang
Welcome you contact me any time!
