Einhell Type/high Quality/competitive Price/5KW 186F Diesel Engine
- Ningbo/Shanghai
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
-
5KW Air-cooled Electric Start Three Phase Diesel Generator
-
Taizhou 100% Copper Wire New Design Single Phase Sound Proof Diesel Generator
-
Sinlet Type 220V/380V 220V/400V 240V/415V Three Phase 5kva Diesel Generator
-
Square Frame With 4 Wheels 5kw Open Diesel Generator
-
3KW-6KW Single Phase 100% Copper Wire Portable Electric Start Diesel Generator
-
Open- Frame Type 2-6KW Electric Single Phase Diesel Generator
Product Details
| Place of Origin | Zhejiang, China | Brand Name | NEWLAND/OEM/ODM | |
| Model Number | DG6500SE | Output Type | AC Single Phase | |
| Speed | 3000/3600rpm | Frequency | 50HZ OR 60HZ AC | |
| Rated Power | 4.5KW | Rated Voltage | 220V/230V/240V | |
| Rated Current | 8.3A |
Product Description
Einhell Type/high quality/competitive price/5KW 186F diesel engine
Feature
1. Overload and low oil warning for safe running.
2. AVR alternator provides stable voltage and current.
3. Powered by 4-stroke air-cooled diesel engine.
4. Large-capacity mufflers for super silent operation.
5. Portable, easy to fit wheels and handle.
6. One year warranty with free spare parts.
Specification
Einhell model/high quality/competitive price/5KW 186FA diesel engine/small silent diesel generator
| DG4500SE-A/B/S | DG6500SE-A/B/S | DG8500SE-A/B/S | |||
| GENERATOR | |||||
| Frequency (HZ) | 50/60HZ | 50/60HZ | 50/60HZ | ||
| Max.output (KW) | 3.3/3.5 | 5/5.5 | 6.5/7 | ||
| Rated output(KW) | 3/3.3 | 4.6/5 | 6/6.5 | ||
| Rated AC Voltage(V) | 120,220,230,120/240,220/380 | ||||
| Power Factor | 1 | 1 | 1 | ||
| DC output (V) | 12V/8.3A | ||||
| Phase | Single Phase | ||||
| Alternator Type | Self-excited,2-pole, Single alternator | ||||
| Starting System | electric | ||||
| Noise Level (dB(A/7m) | 68-72 | ||||
| Fuel Tank Capacity (L) | 16 | 16/30 | |||
| Continuous Running Time (hr) | 8.5/7.8 | 8.5/7.8 | 8.5/7.8 | ||
| ENGINE | |||||
| Engine Model | 178F | 186FA | 192FB | ||
| Engine Type | single-cylinder, vertical,4-stroke, air-cooled diesel engine | ||||
| Bore×Stroke | 78×64 | 86×72 | 92×75 | ||
| Fuel Consumption rate g/kw/h | ≤295 | ≤280 | ≤280 | ||
| Fuel | 0# or -10# light diesel oil | ||||
| Lubrication Oil Volume (L) | 1.65 | ||||
| Combustion System | Direct Injection | ||||
| STANDARD FEATURES | |||||
| Voltmeter | YES | ||||
| AC Output Socket | 2 | 2 | 2 | ||
| AC Circuit Breaker | YES | YES | YES | ||
| Oil warning Light | YES | YES | YES | ||
| Oil Alert | YES | YES | YES | ||
| OPTIONAL FEATURES | |||||
| DC circuit breaker | OPTIONAL | ||||
| Four sides wheel | OPTIONAL | ||||
| Three phase voltage | OPTIONAL | ||||
| Digital meter | OPTIONAL | ||||
| ATS | OPTIONAL | ||||
| Remote control | OPTIONAL | ||||
| Welding | OPTIONAL | ||||
| PACKING | |||||
| Dimention(LxWxH)(cm) | 85*56*76 | 95*56*76 | 95*56*76 | ||
| Net Weight(kgs) | 144 | 155 | 156 | ||
| Container quantity 20GP | 72 | 72 | 72 | ||
| 40HQ | 144 | 144 | 72 | ||
Taizhou Newland Machinery Co., Ltd is a professional supplier of gasoline generator, diesel generator, pumps, engines, gasoline high pressure washer etc. Over 10 years OEM/ODM exporting experience to more than 50 couintries and area. Fast-delivery time (15-20days for new customers, 7-10days for regular customers) and the monthly output ( over 30000 units ) ensure Newland to be of your best choice.
Show Room
Work Shop
Advanced and industy-leading equiptments.
Quality control from the raw material and spare parts.
Production
Strictly quality control during the production precedure
Every product must be passed three testing program.
Product Testing
Spot checking double guarantee qualified products for shipping
Ware house
Carfully loading
Efficiency container space utilizing
Exact quantity
1.Q: What is the Trade terms? What’s the nearest port?
A: EXW, FOB, CFR, CIF.(Taizhou)
2.Q: What is your MOQ of this item?
A: 10 sets
3.Q: Are you manufactory or Trading Company?
A: We are trading company based on our own factory
in Zhejiang province, China
4.Q: Is it all right to make customer's own brand name
A: Sure, with your authorization of brand.
We have over 10 years OEM/ODM experience.
5.Q: What are your payment terms?
A: T/T 30% deposit, 70% balance should be paid against the B/L copy.
D/P for regular good reputation customers.
6.Q: How long is your warranty?
A: One year or 500hours (accord to whichever reach first) from Ex-Factory date.
7.Q: What is the delivery time?
A: 20-25days after receiving your deposit or original L/C.
8.Q: What is your company production capacity?
A: 20000-30000 Sets per month against your orders
9.Q: Which engine type about your products?
A: 1-Cylinder;4-stroke,air-cooled diesel engine
10.Q: Is your rotor and stator aluminum wire or copper wire?
A: 100% copper
