Electron Component : Bimetal Jumping Disc
Wuhu Boton Automobile Parts Factory is a professional manufacturer with Boton brand and self-developement capacity. Our core competencies is thermostatic bimetal components, thermometer, jumping disc toys, heating chamber for engine carburetors, auto generator regulars,various auto glass lifter motor protector.
Bimetal thermostat consists of two or more metallic layers which have
different thermal expansion bended together.When heated up,it bends in a pre-determined manner and can be used to measure,regulate and control temperature.
The main application of bimetal thermostat disc for heating chamber of silicon oil fan clutch lies in the sensitivity for temperature change.And also they can used as a switch in controlling devices in automobiles.
Bimetal thermostat also can be manufactured as spiral and stripe which can give a snap action to temperature change.
1. 16 years experiences and professional R&D team provides you professional development proposal and customized product.
2. 1.000.000 times fatigue testing ensures the reliable performance
3. From beginning to end, from sample to shipping, we can handle your entire project, which makes your business easier.
4. ISO certified, Supplier of Kohler CO, Exclusive supplier of China FAW Group Corporation, this is how we keep good quality and reliable cooperaion for global valued customers.
The jumping disc is made from a special piece of metal, called bi-metal that moves when heated with your thumb. When it is warmed to about body temperature, you can "click it" into its loaded position and then carefully place it on a hard surface. When it cools down to room temperature, it suddenly snaps back into the old position, and simultaneously jumps high up in the air. It jumps several hundred times its own height.
The jumping disc toy works on the same principle as a thermostat or a shunt-valve in your car. With such a thermostat or automatic valve, a special piece of metal, called bi-metal, moves when heat is applied or removed. Bi-metal is actually two pieces of thin metal fused together in the middle. When the temperature changes, the metals expand differently and bend into a curve in either direction.
For instance, when the temperature drops in your home the bi-metal in your thermostat cools down, moves a little, hits a contact and turns on a heater. This way the temperature stays the same. In a car, the metal disc made of bi-metal opens or closes the valve to the radiator, so the water stays about the same temperature to make the engine run well.
In the case of the jumping disc, the bi-metal stays in one position when at room temperature, and in another position when at body temperature. First you warm it to body temperature in your hand, and then you snap the disc between your fingers so it stays in this “new” position. Now you carefully, and quickly, slide it onto a hard surface, like a table. In a few seconds the disc cools off, suddenly snaps back into the regular position, and with a loud “click” flies high into the air!
