1. Structure and characteristics
YTD27 series Hydraulic Press Machine move lamella to hurtle to press a liquid to press machine for the list, YTD28 series move lamella to pull to stretch a liquid to press machine for the double. That machine is the ideal equipments that the medium small scaled metals lamella ware pulls to stretch to take shape. Being applicable to the aviation, car, tractor, motorcycle, tool machine, appearance, chemical engineering, kitchen cooking stove has home appliances etc. profession.
That machine presses side device for sectional, pack to unload convenience, make machine the orientation pulls to stretch a craft, besides which, have in the meantime all-powerful press the function of machine, be applicable to plastics ware, powder ware, metals mold to inhibit an article to take shape extensively and blunt carry, curve, correct, turn over a side and press to pack etc. craft.
The machine has adjustment, hand to move, the automatic single circle is three kinds of work methods. Work pressure, work route of travel all can inside certain scope arbitrarily inside adjust arbitrarily. Have higher empty transport to go inside speed and reasonable scope of adjustable pull to stretch speed.
The machine operates simple, the function is dependable, maintaining convenience, can single machine work, can also with kit auto flowing water homework.
The machine takes to return to oil cooling to equip also, can control an oil temperature and promise machine availably to circulate in a row and normally.
The control system of the machine electric appliances adopts programmable preface controller,various breakdowns report to the police indicator.
2. Technical Data
| Iten | Unit | YTD28-63/100 | YTD28-100/180 | YTD28-200/300 | YTD28-315/400 | YTD27-200 | YTD27-315 | YTD27-2000 | |
| Nominal Pressure | KN | 1000 | 1800 | 3000 | 4000 | 2000 | 3150 | 20000 | |
| Stretch Force | KN | 630 | 1000 | 2000 | 3150 | 0 | 0 | 0 | |
| Ejecting Force | KN | 100 | 630 | 630 | 630 | 630 | 1000 | 1000 | |
| Nearby Pressure Force | KN | 300 | 800 | 1000 | 800 | 600 | 800 | 1000 | |
| Working Pressure | Mpa | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
| Control Circuit Pressure | Mpa | 1.2-1.5 | 1.2-1.5 | 1.2-1.5 | 1.2-1.5 | 1.2-1.5 | 1.2-1.5 | 1.2-1.5 | |
| Slide Max. Travelling Range | mm | 500 | 700 | 700 | 800 | 560 | 800 | 900 | |
| Nearby Pressure Max. Travelling Range | mm | 300 | 350 | 400 | 300 | 260 | 300 | / | |
| Ejecting Max. Travelling Range | mm | 200 | 350 | 400 | 350 | / | / | / | |
| Stretch Slide Opening Height | mm | 1100 | 1200 | 1400 | 1400 | 900 | 1140 | 1350 | |
| Nearby Pressure Opening Height | mm | 700 | 750 | 900 | 800 | / | / | / | |
| Vaild Work Table Area | mm | 560*500 | 630*630 | 1000*900 | 1260*1120 | 1000*900 | 1260*1120 | 9000*1000 | |
| Speed | Empty Slow Descending | mm/s | 100 | 100 | 100 | 100 | 210 | 100 | 60 |
| Empty Fast Descending | mm/s | 20 | 20 | 20 | 40 | / | / | / | |
| Stretch Speed | mm/s | 10-20 | 10-20 | 10-20 | 10-30 | 18 | 40 | 2-6 | |
| Return Trip Speed | mm/s | 100 | 100 | 100 | 200 | 200 | 200 | 70 | |
| Eject Speed | mm/s | 95 | 95 | 95 | 160 | / | / | 80 | |
| Return Speed |
mm/s | 220 | 220 | 220 | 350 | / | / | 120 | |
| Main engine overall size | L-R | mm | 2500 | 2300 | 3800 | 4000 | 3800 | 4000 | 9000 |
| F-B | mm | 1500 | 900 | 1800 | 2800 | 1800 | 2800 | 2100 | |
| Height | mm | 3200 | 3600 | 4400 | 4600 | 4400 | 4800 | 5600 | |
| Motor Power | KW | 7.5 | 22 | 37 | 37 | 22 | 22 | 90 | |
| Weight | KG | 4200 | 6500 | 18000 | 25000 | 13000 | 16000 | 91000 | |
