HD-Y41 Series Single-Column Hydraulic Press Machine

HD-Y41 Series Single-Column Hydraulic Press Machine thumbnail-1
HD-Y41 Series Single-Column Hydraulic Press Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Power Source:
Hydraulic
Contact Supplier Request Quote Chat Now
Xiamen Chengyang Mechanical & Electrical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Any Chinese Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
CNC or Not Normal
Power Source Hydraulic
Place of Origin Fujian, China
Brand Name chengyang
Model Number HD-Y41

HD-Y41 Series Single—Column Hydraulic Press



Application: This series of single column hydraulic press is used in correcting bearings and parts alike. They can also be used in drawing, forming and blanking bearings and sleeve.



Features  :

  •    Hand-foot linkage operation
  •    Easy to operate and repair
  •    Integrated instrumentation in hydraulic system
  •    Compact structure, low energy consumption and low working noise.

HD-Y41 Series Hydraulic Press With Four Columns



NO. Technical parameter Unit Model
HD·Y41 HD·Y41 HD·Y41 HD·Y41 HD·Y41 HD·Y41 HD·Y41 HD·Y41
-10B -16 -25B -40D -63D -100E -160D -250B
1 Rate pressure KN 100 160 250 400 630 1000 1600 2500
2 Max.hydraulic ic pressure Mpa 20 25 21 25 25 25 25 25
3 Slide to work floor
maximum range		 Adjustment mm 450 450 430 510 550 500 650 560
Press mounting mm 630 630 630 710 800 800 1000 1000
4 Slide Stravel mm 400 400 500 500 500 500 500 500
5 Slide maximum downward speed mm/s 50 45 ≥35 40 30 24 ≥20 ≥20
Slide maximum return speed mm/s 80 100 ≥85 80 70 50 ≥80 ≥70
6 Working speed mm/s 25 20 17 20 15 12 10 10
7 Throat depth mm ≥210 250 320 320 320 320 320 320
8 Work table size Press
mounting		 Long·width mm 410×420 450×500 510×580 560×560 630×600 710×600 800×600 850×660
Adjust
ment		 Long·width mm 1000×180 1000×180 1250×200 1250×200 1600×250 2000×300 2000×250 2500×600
9 Falls the material aperture mm Ø140 Ø160 Ø180 Ø200 Ø200 Ø200 Ø200 Ø150
10 Machine overallsize About mm ≈655 735 775 1250 1600 2000 2000 1100
Around mm ≈1160 1350 1480 ≈1660 ≈1750 2000 2000 2000
Highly mm ≈2100 2160 2330 ≈2370 2500 1650 2954 3350
11 Motor power KW 4 5.5 5.5 7.5 7.5 11 15 18.5
